Low Energy-consumin Pin Cold Feed Rubber Extruder Reclaimed Rubber Machinery XJD Serie

Low Energy-consumin Pin Cold Feed Rubber Extruder Reclaimed Rubber Machinery XJD Serie thumbnail-1
Low Energy-consumin Pin Cold Feed Rubber Extruder Reclaimed Rubber Machinery XJD Serie photo-1
Negotiable MOQ: 1 Kilogram (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Brand Name:
MC
Place of Origin:
China
Model Number:
XJD
Contact Supplier Request Quote Chat Now
Machine International Trade Co., Ltd
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
7 days

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name MC
Place of Origin China
Model Number XJD
Delivery Time:45 days
Certification:CE SGS ISO

XJD series pin type cold feeding rubber extruder machine of rubber porduction line

1. Structure

  The machine constitude of Charging hopper, barrel, screw, the top group and ect

2. Application

  Pin Cold Feed Rubber Extruder is applicable to extruding types of tread in radial tyre and cross-ply tyre preparation, extruding bead apex,covering rubber of electric wire, electric cable and rubber hose ,extruding rubber board, slab, conveyer belting and rubber core. Also the extruder is widely used for feeding rubber for radial tires airtight seal.

 3. Advantages

(1) The extruder uses the technology of room temperature feeding.

(2) High quality, high yield ability, high efficiency and energy conservation.

(3) Extruder can extrude rubber at low temperature, and is highly adaptable to processes of types of rubber sizing material.

(4) The extruder is the first choice machine while technology innovating, process improving and equipment replacing in rubber industry.

Parameter

type
screw diameter
(mm)
length-diameter ratio of the screw
revolving speed of the screw(r/min)
maximum production capacity(kg/h)
driving power(kw)
machine weight(T)
overall dimension(mm×mm×mm)
XJD-50
φ50
12:1
7-73
60
11
1.1
L1550×W1050×H1500
XJD-65
φ65
12:1
8-75
120
30
1.65
L1900×W800×H1500
XJD-75
φ75
14:1
6-60
180
37
1.7
L2340×W1150×H1250
XJD-90
φ90
12:1
7-76
400
55
2.5
L2440×W1000×H1450
XJD-120
φ120
16:1
5-50
1000
110
5
L1600×W1100×H1000
