55KW pin type cold feed rubber extruder machine of rubber porduction line , cold feeding extruder
- 0 Metric Ton / Metric Tons per Month
- T/T L/C D/P D/A
- 7 days
You May Like
-
XK-450 two roller 450mm diameter 1200m length rubber open mill machinery
-
Waste tyre recycling machine for rubber powder production line / recycling plant
-
Professional rubber powder production line / 900-1200mm waste tyre cutting machine
-
Reclaimed rubber machinery chilled cast iron / 900-1200mm tyre cutting machine
-
Low energy consume rubber strainer machine for rubber production plant XJL-Y series
-
Professional reclaimed rubber devulcanization machine for devulcanizing hopper
Product Details
| Brand Name | MC | Place of Origin | China | |
| Model Number | XJP |
Product Description
Certification:CE SGS ISO
XJP series exhaust type cold feeding rubber extruder machine of rubber porduction line
1.Structure
The machine constitude of Charging hopper, barrel, screw, the top group and ect
2.uses
Pin Cold Feed Rubber Extruder is applicable to extruding types of tread in radial tyre and cross-ply tyre preparation, extruding bead apex,covering rubber of electric wire, electric cable and rubber hose ,extruding rubber board, slab, conveyer belting and rubber core. Also the extruder is widely used for feeding rubber for radial tires airtight seal.
3.Features
(1) The extruder uses the technology of room temperature feeding.
(2) High quality, high yield ability, high efficiency and energy conservation.
(3) Extruder can extrude rubber at low temperature, and is highly adaptable to processes of types of rubber sizing material.
(4) The extruder is the first choice machine while technology innovating, process improving and equipment replacing in rubber industry.
Parameter of rubber strainer extruder
|
type |
Screw diameter (mm) |
Length-diameter ratio of the screw |
Revolving speed of the screw (r/min) |
Maximum production capacity(kg/h) |
Driving Power(kw) |
Machine weight(T) |
Overall diamension |
|
XJP-90 |
Φ90 |
16:1 |
7.5-75 |
400 |
55 |
2.5 |
L2600*W560 *H1300 |
