Home > Products > Precision Steel Tube > Precision Steel Tubes GOST9567 10 20 35 45 40X 30 Alloy Steel Tubes
Precision Steel Tubes GOST9567 10 20 35 45 40X 30 Alloy Steel Tubes
USD $ 600 - $1200
/ Set
1 Set(Min.Order)
- 0 Set / Sets per Month
- T/T L/C D/P D/A
- 7 days
You May Like
-
Round Cold Drawn Welded Precision DOM Steel Tube With +C +LC +SR +A +N
-
Hydraulic Systems EN10305-4 Seamless Cold Drawn Tube with Cold Rolling Production
-
Outside Square Inside Round Special Steel Pipe , Seamless Carbon Alloy Tube
-
24mm Wall thickness Welded Rectangle Special Steel Pipe ST37.0,ST44.0
-
Rectangle Special Steel Pipe , Metal Square Tubing For Agricultural Machinery
-
ASTM A106 A53 API 5L Structural Steel Pipe , Carbon Steel Seamless Tube
Product Details
| Brand Name | TORICH | Place of Origin | China | |
| Model Number | GOST9567 |
Product Description
Certification:ISO 9001 ISO 14001 EN 10204.3.1 TS 16949
GOST9567 10 20 35 45 40X 30ХГСА Steel Tubes-Precision Steel Tubes
GOST9567 Precision steel tubes
Applications: Automobile, Machinery Engineering, Autoparts etc.
Size range: O.D.:6-168mm W.T.:1-15mm L:max12000mm
Chemical Composition(%,max)
| Steel grade | C | Si | Mn | Cr | Ni | Mo | S | P | Cu |
| 10 | 0.07-0.14 | 0.17-0.37 | 0.35-0.65 | 0.15 | 0.3 | - | - | - | - |
| 20 | 0.17-0.24 | 0.17-0.37 | 0.35-0.65 | 0.25 | 0.25 | - | 0.03 | 0.025 | 0.3 |
| 35 | 0.32-0.40 | 0.17-0.37 | 0.50-0.80 | 0.25 | 0.3 | - | 0.04 | 0.035 | 0.3 |
| 45 | 0.42--0.45 | 0.17-0.37 | 0.50-0.80 | 0.25 | - | - | - | - | - |
| 40X | 0.36-0.44 | 0.17-0.37 | 0.50-0.80 | 0.80-1.10 | 0.3 | - | 0.035 | 0.035 | 0.3 |
| 30ХГСА | 0.28-0.34 | 0.90-1.20 | 0.80-1.10 | 0.80-1.10 | 0.3 | - | 0.005 | 0.025 | - |
Mechanical Composition
| Steel grade | Tensile strength, N/mm2 (min) |
Yield strength, N/mm 2 (min) | Elongation, %(min) |
| 10 | 343 | 206 | 24 |
| 20 | 412 | 245 | 21 |
| 35 | 510 | 294 | 17 |
| 45 | 589 | 323 | 14 |
| 40X | 618 | - | 14 |
| 30ХГСА | 491 | - | 18 |
Production and Quality Inspection:
