Certification:CE/CCC/ SGS
24V 60W Brush DC Sliding Glass Door Motor For hold open hotels banks
Description:
Brush gear dc motor supported by intelligent Honeywell software can self-learn the stroke. The brush motor and the worm-reduction gear are integrated together, with advantageous features such as higher efficiency, larger torque and longer life span. The motor noise is extremely low because of its precise manufacturing technology and direct driving design. The motor can lock automatically if there is no triggering signal. The powerful closing force keeps the door shut fast.
Applications:
This kind of brush gear dc motors are used for Automatic sliding door operators, interior door operators, telescopic door operators, automatic swing door operators, emergency evacuation automatic doors and curved doors, which are widely used in hotels, banks, airports, commercial buildings, hospitals and factories.
Specifications:
Sliding Glass Door Motor Specs:
|
Type |
Brush |
|
Voltage |
24VDC |
|
Power |
60W |
|
No load Speed |
250rpm |
|
No load Current |
0.7A |
|
On load Speed |
200rpm |
|
On load Current |
3.5A |
|
Stall torque |
12Nm |
|
Protection class |
IP44 |
|
Weight |
1.5kg |
|
Encoder Honeywell |
1signal,40pulse |
Outline drawings of Sliding Glass Door Motor:
Competitive Advantage:
1) Silent operation, suitable for continuous service;
2) Micro-computer controller, self setup and adjustment;
3) Automatic stop when meet obstacles during opening, automatic reverse when meet obstacles during closing;
4) Adjustable door opening speed and distance;
5) Automatic closing function after opening, auto closing time adjustable;
6) Soft start and soft closing;
7) Full open or half open optional;
8) Easy open the door leaf by hands during power off;
9) High density aluminum track, special configuration design keep in shape always;
10) Smooth operation of the track, good for continuous service, quiet operation.
