High Power Low Noise Sliding Glass Door Motor Brushless Safety with Automatic Stop
Description:
1) Input power supply AC110V-240V;
2) DC24V brushless motor
3) Door Weight 300kg/single leaf, 2X150kg/ Double leaves
4) Door Width: 650~1600mm
5) Maximum Noise below 50dB
6) Railing Type: High Strength Aluminum Alloy Rally
7) Fixed Pulley Hanging Wheel Sets/Convenient Level Adjustment/Automatic Alignment/Easy Installation
8) Working Temperature-25~ c+55 c
Applications:
This Heavy duty automatic Sliding door round motor type Brushless DC Motor can be used on any kinds of Automatic doors: Sliding Door, Swing Door, Curved Door, Folding Door, Hermetical Door, Telescopic Door, Panic Door, Revolving Door, and Hospital Door etc. Which are widely used in Hotel, Hospital, Shopping Mall, Bank, Commercial office building and etc.
Specifications:
Round type Brushless dc motor:
|
Type |
Brushless |
|
Voltage |
24VDC |
|
Power |
100W |
|
No-load speed |
150rpm |
|
On-load speed |
120rpm |
|
Noise level |
≤50dB |
|
Protection class |
IP44 |
|
Gear Ratio |
1:15 |
|
Weight |
2.5 kg |
|
Lifetime |
3million cycles,10years |
|
Application |
Automatic Sliding door |
Motor Outline drawings:
Competitive Advantage:
1. LOW NOISE than brushed motor, because of its precise manufacturing technology and direct driving design.
2. Brushless motors have LONG LIFE than brushed motors (more than 3,000,000 cycles), with 10years warranty.
3. Small size and Excellent Design, high-strength wear-resistant gears and high processing makes it more stable, quiet, longer life, higher efficiency, larger torque.
4. Leading technologies, multi- functions, dependable performance while being cost efficient.
5. Widely used for Automatic Doors: including Sliding Door, Swing Door, Curved Door, Folding Door, Hermetical Door, Telescopic Door, Panic Door, Revolving Door, Hospital Door, be installed in the hotels, airports, office buildings, shopping malls, hospitals etc.
