Shot Blasted Drilling , Tapping CNC Turning Services For Telecommunication

Delivery Time:30 days
Certification:ISO, SGS, CMA, CNAS

Shot Blasted Drilling , Tapping CNC Turning Services For Telecommunication

Quick Detail:

Materials option includes wild steel, tool steel, aluminum alloy, copper, brass, Zamak, stainless steel, plastic, Kovar etc; CNC turning is the main process for such parts with round shapes, but may also involve the followings like surface grinding, cylindrical grinding, optical grinding, CNC boring, Wire EDM, drilling, tapping etc; Surface finish can be color anodized, passivated, electroplating or even powder coated; Final dimensions fully checked by our QA people before shipping, no compromise on quality; Roughness and hardness as per the prints or even better; We can support your prototypes development, please contact us; Flatness, parallelism, perpendicularity, roundness to be 0.05mm or less.

Description:

CNC turning is such a process, mainly employed to machine parts with round shapes. We call the machine which does the turning process a lathe. Nowadays most of our lathes are with CNC system. We also have some conventional lathes. Turning process is very common one as we can see round parts everywhere. For high volume parts, the material bars can be fed to the lathes automatically, and the machine will do the pre-coded processes and cut the bar one (part) after another. Perfect heat treatment process. Surface polished or grinded.

Applications:

Defense, auotmotive; Telecommunication, consumer electronics; Industrial equipments, medical device; Aerospace, oil and gas; LED lighting; Monitors; Infrastructure and processing equipments, gear motors etc.

Specifications :

1) Material	Wild steel, tool steel, aluminum alloy, copper, brass, bronze, Zamak, stainless steel, plastic, Kovar, sheet metal etc
2) Finishing and Treatment	Shot blasted, anodized, electroplating, passivated, painted or powder coated, quench and temper, annealing etc
3) Equipments involved	CNC machining/milling center, CNC boring center, surface grinding, cylindrical grinding, wire EDM, tapping machine etc
4) Processes involved	CNC milling, drilling, tapping, boring, grinding
5) Dimensional tolerance	±0.02mm or less
6) Geometric tolerance	±0.05mm or less
7) Roughness	Ra 0.08 or less
8) Production capacity	10,000pcs per month
9) Quality inspection	IQC, PQC, FQC
10) Lead time	30 days
11) Place of delivery	Shenzhen, China

Competitive advantages:

Adhere to specification, quick response, fast delivery; Cost effective, quality guaranteed; Comprehensive machining processes and knowledge of finishing, treatment requirements, Tapping and insertion of heli-coils etc; Our turning/milling centers can produce parts with most complicated features and highest precision; PPAP for parts.
