Help Center1kw Vertical Axis Wind Turbine
Related Products
Performance:
Rated Power: 1 KW
Max Power: 1.2 KW
Rated Wind Speed: 12 m/s
Cut-In Speed: 2.5 m/s
Cut-Out Speed: 25m/s
Survival Wind Speed: 50 m/s
Physical Parameters:
Mill Diameter: 1.8 m
Mill Height: 2 m
Mill Weight: 200 Kg
Tower Height & Weight: 5.5m(235Kg)
Generator Parameters:
Type: PMG 3 Phase
Rated Voltage: AC 250V Rated Current: AC 2.3A
Protection Level: IP54
Controller Output:
Output Voltage(On-grid): DC 60-375V
Output Voltage(Off-grid): DC 24/48V
Over Speed Protection & Braking System:
Speed Control Style: Pitch Control System
Brake Style: Automatic Magnet Brake
Advantages of VAWT:
Nearly Quiet
Birds Friendly
More Safety Features
Wonderful Performance at Low Wind Speed
Captures Wind from All Directions
Longer Working Life
Less Maintenance
Less Requirements on Foundation
Lower Supporting Tower
Advantages over Other VAWT:
High Efficiency
Pitch Control to Govern Speed
Automatic Magnet Brake
