Certification:CE/CCC/ISO9001
YLJX Three phase torque motors in Industry ( H90 Cast Iron Frame)
12v high torque small motors
1. voltage range:3.0-24.0V
2. high speed,high torque
3. size:35.7D*57.0L mm
4. weight:215g
|
Ambient |
|
|
Temperature range: |
-15~40℃ |
|
Ambient humidity: |
90%less than relative humidity |
|
Altitude: |
less than 1000m above sea level |
|
Ambient condition: |
no causticity gas, no dust, no heavy mental pollution, no flame, no salt crystallization |
|
Supply power: |
|
|
Voltage variable |
±5% |
|
frequency variable |
±2% Combine voltage and frequency variable : ±5% |
|
Standard Feature: |
|
|
Standard |
IEC |
|
Phase |
Three-phase |
|
Frame Size |
H90 Cast iron frame |
|
Frequency |
50HZ |
|
Cooling type |
Self cooling |
|
Voltage |
380V |
|
Poles |
2,4,6,8 |
|
Connection |
Y |
|
Certification |
CCC, CE,ISO9001 |
|
Special motors can be designed according to customers\' requirements |
Meaning of type code
Technical Specification
|
Type |
Frame (mm) |
Moment (N.m) |
Pole |
Maximum Current |
Locked Time (min) |
|
YLJX90-2-2 |
90 |
2 |
2 |
2.5 |
15 |
|
YLJX90-3-2 |
3 |
3 |
|||
|
YLJX90-3-4 |
3 |
4 |
1.5 |
||
|
YLJX90-3.5-4 |
3.5 |
1.9 |
|||
|
YLJX90-2.5-6 |
2.5 |
6 |
1.1 |
||
|
YLJX90-3-6 |
3 |
1.5 |
|||
|
YLJX90-2-8 |
2 |
8 |
1.2 |
||
|
YLJX90-2.5-8 |
2.5 |
1.4 |
Mounting and Overall Dimensions(mm)
|
Frame Size |
Mounting Dimensions (mm) |
Overall Dimensions (mm) |
||||||||||||||||||||
|
A |
B |
C |
D |
E |
FXGD |
G |
H |
K |
T |
M |
N |
P |
S |
AB |
AC |
AD |
HD |
AA |
BB |
HA |
LA |
L |
|
YLJX 90S |
140 |
100 |
56 |
24 |
50 |
8*7 |
20 |
90 |
10 |
3.5 |
