IP65 Outdoor PLC Splitter Fiber Optical Distribution Box Wall Mounted
Negotiable
/ Piece
1 Piece(Min.Order)
- 0 Piece / Pieces per Month
- T/T L/C D/P D/A
- 7 days
You May Like
-
48core 3U ODF Fiber Optic Distribution Box , Rack Mounted Structure
-
12port Fiber Optic Distribution Box , Welding Distribution Module Tray for ODF Unit Box
-
1*4 PLC Outdoor Fiber cable distribution box for SC Fiber Pigtail
-
4 port Indoor fiber distribution box , 4 fibers Customer Terminal Box
-
ABS Housing 4 Port Fiber Optic Distribution Box for Data communications networks
-
Wall and pole mountable 32Port FTTH CATV outdoor distribution box for 1*32 PLC Splitter
Product Details
| Brand Name | TTI | Place of Origin | China | |
| Model Number | FDB-32D |
Product Description
Certification:ROHS, SGS
IP65 Outdoor PLC Splitter Fiber Optical Distribution Box Wall Mounted
Description:
This plastic distribution box,with insert-stlye splitters,suitable for outdoor,corridor or weak current silo. It can be used for local cable or drop cable end and sub-distribution; also it can be used for protective connection of cable and layout pigtails,and fiber optic terminations of access network,with the advantage of light,small,convenience of transportation and installation and capacity of 16 cores or 32 cores.
Feature:
The box is made of imported flame retardant material,with aging resistant and ultra violet resistant characters; Sealing with pressed strip,waterproof and dustproof with Ip65; Special screw and key for its door lock,can be installed on wall or mounted on pole; Spare pigtails and droop cable can be save in the storage part,convenience for maintenance; Special lock device for outlet of drop cable,Bilayer structure,bottom for splicing and upper layer for splitting and distribution.The installing plate can be turn over for convenience of installation and operation; With 2/4 standard slot position for the installation of insert-style splitters of 1:8,1:16,1:32; Maximum 2 pcs of splice tray for satisfying kinds of connection.Application:
Widely used in FTTH access network. Telecommunication networks. CATV Networks. Data communications networks. Local Area Networks.Specification:
| Model | TTI/FDB-32D |
| Size(mm): L*W*H | 350*340*120 |
| Cable ports | 4 cable ports |
| Max capacity of splice | 1pcs 1*32PLC |
| Net Weight (kg) | 3.48 |
| Outer carton weight (kg) | 22.3 |
| Package | 6PCS/CTN |
Shipping:
Door to Door: by express (such as DHL, UPS, TNT, FedEx etc.) Airport to Airport: by air Seaport to Seaport: by sea (our location Shenzhen is a seaport.)Contact Us
