P10.417 Stage Background LED Screen Advertising For Gov Publication
- T/T L/C D/P D/A
- 7 days
You May Like
-
Outdoor Curtain P12.5mm Lightweight LED Display For Events , Show
-
Aluminum Lightweight LED Display , P15.625 LED Display Signs
-
CE Waterproof P10 SMD Billboard LED Display For Wedding , Conference
-
SMD Flexible Indoor LED Display Screen Signs P6 For Concerts , Trade Show 1R1G1B
-
1R1G1B P4 Indoor Full Color LED Display Signs Rental For Stage , Event 2000 Cd/m2
-
DIP P20 Outdoor LED Display Board , 1R1G1B Sports Perimeter LED Display For Basketball Pitch
Product Details
| Brand Name | Newstar-LED | Place of Origin | China | |
| Model Number | WS-10 |
Product Description
Certification:CE, RoHS, UL, FCC, ISO
Quick Detail:
1. Waterproof Level: IP65(Front Side), IP54 (Back Side)
2. CE,CCC,RoHS,UL,ISO900
3. Lightweight :< 12.5KG/panel. Ultra thin: 95mm thickness
4. High brightness: >6000cd/㎡
5. Package with flight case, easy to move
6. Special cabinet design, cooling fast
P10.417 Stage Background LED Screen Advertising For Gov Publication
Description:
1. Angle Adjustment
Cabinet connection angle can be adjusted by -15 degree to +15 degree. This allows you shape arc
shapes.
2. High brightness & Waterproof
Brightness reaches 6000nits, IP65. It is perfect to be used for both indoor and outdoor.
3. Light Weigh & Ultra Thin
Made by high quality aluminum material, one cabinet only weights 12.5 KG. It makes installation job and
delivery more comfortable and convenient. 95 mm thickness saves not only space for delivery but also
installation.
4. Fast Lock System & No Fan Design
Easy to install and dismantle: an average worker can finish 70 panels per hour. Natural cool system design
and good heat dissipation.
Applications:
Live broadcast: Gym, Stadium, Concert, Sport match, Competition, Gov publication etc.
Rental business: Entertainment, Wedding, Party etc.
Specifications:
1. Indoor LED Display Technical Parameter
|
Brightness |
≥6000 nit |
|
Color temperature |
6500/9000 K |
|
Viewing angle-H |
140 (+708-70) deg. |
|
Viewing angle-V |
140 (+708-70) deg. |
|
Cabinet weight |
12.5 kg |
|
Cabinet size (W×H×D) |
500×1000×95 mm |
|
Cabinet area |
0.5 sqm. |
|
Cabinet material |
Aluminum |
|
Ingress protection (Front/Rear) |
IP65/IP54 |
|
Operating temperature |
–20~+60 degree |
|
Operating humidity |
10%~ 90% |
|
Pixel configuration |
1R1G1B |
|
Pixel pitch |
10.417 mm |
|
Module size |
250x250 mm |
|
Pixel matrix per module |
24x24 dots |
|
Pixel matrix per cabinet |
48x96 dots |
|
Pixels per cabinet |
4608 dots |
|
Pixels per sq.m. |
9216 dots |
|
Minimum viewing distance |
10 m |
|
Gray scale |
4096 level |
|
Brightness control |
256 level |
|
Refresh frequency |
>1000 Hz |
|
Driving mode |
1/6 scan constant current driving |
|
Input voltage (AC) |
100 ~ 240 V |
|
Input power frequency |
50 or 60 Hz |
|
Power consumption per sq.m. (max/avg) |
800/300 W |
|
Blind spot rate |
<1/10000 |
|
Lifetime at 50% brightness |
100000 hours |
|
Red wavelength (Typical) |
