Aluminum Lightweight LED Display , P15.625 LED Display Signs

Name: Aluminum Lightweight LED Display , P15.625 LED Display Signs
Brand: Newstar-LED
SKU: 149627722
Availability: InStock

Newstar Optoelectronics

Negotiable MOQ: 1 Meter (Price negotiable depending on order volume and customization)

Key Specifications

Brand Name:

Newstar-LED

Place of Origin:

China

Model Number:

WS-15

Payment & Shipping

Payment Methods:

Port of Shipment:

China

Delivery Detail:

7 days

Brand Name Newstar-LED

Place of Origin China

Model Number WS-15

Delivery Time:8-25days after received the payment
Certification:CE, RoHS, UL, FCC, ISO

Quick Detail:

1. Special cabinet design, cooling fast

2. Wonderful product especially for stage use.

3. Available models: P10.417, P12.5, P15.625.

4. Package with flight case, easy to move.

5. No tools needed, can be installed with 1 person.

6.Cabinet material: Aluminum

Aluminum Lightweight LED Display , P15.625 LED Display Signs

Description:

1. Fast lock design help to fast install

No tools needed, can be installed with 1 person.

2. Slim Design

One cabinet size is 500 x 5000 x 94mm

3. Can adjust the screen be curved

Panel connection angle can be adjusted by -15 degree to +15 degree. This allows arc shape available.

Applications:

Live broadcast: Gym, Stadium, Concert, Sport match, Competition, Gov publication etc.

Rental business: Entertainment, Wedding, Party etc.

Specifications:

1. LED Curtain Technical Parameter

Brightness	≥5000 nit
Color temperature	6500/9000 K
Viewing angle-H	140 (+708-70) deg.
Viewing angle-V	140 (+708-70) deg.
Cabinet weight	8 kg
Cabinet size (W×H×D)	500×1000×95 mm
Cabinet area	0.5 sqm.
Cabinet material	Aluminum
Ingress protection (Front/Rear)	IP65/IP54
Operating temperature	–20~+60 degree
Operating humidity	10%~ 90%
Pixel configuration	1R1G1B
Pixel pitch	15.625 mm
Module size	250x250 mm
Pixel matrix per module	24x24 dots
Pixel matrix per cabinet	48x96 dots
Pixels per cabinet	4608 dots
Pixels per sq.m.	9216 dots
Minimum viewing distance	10 m
Gray scale	4096 level
Brightness control	256 level
Refresh frequency	>1000 Hz
Driving mode	1/6 scan constant current driving
Input voltage (AC)	100 ~ 240 V
Input power frequency	50 or 60 Hz
Power consumption per sq.m. (max/avg)	800/300 W
Blind spot rate	<1/10000
Lifetime at 50% brightness	100000 hours
Red wavelength (Typical)	623 nm
Green wavelength (Typical)	523 nm
Blue wavelength (Typical)	475 nm
Signal input format (with video processor)	AV, S-Video, VGA, DVI, YPbPr, HDMI, SDI
