HD Seamless Bird View Car Rearview Camera System For Merceders Benz AVM System
Quick Details:
Type: 360 degree around view monitor system
Voltage: DC 12V
Car make: for Mercedes Benz
Resolution: 580TVL
Effective pixel: 720*480
MOQ: 10 set
Place of origin: Guangdong China.
Description:
This system is a parking aid, provides all-round visibility 360 degrees,
while the video viewing is produced around the vehicle. The system
receives four video cameras with wide angle, through seamless splicing
technology to combine these into one (seamless) thus obtaining round
visibility space around the vehicle \"bird\'s-eye\" and the video output on
the screen in real time.
high-tech solutions
As part of the system used for video processing solutions from NXP Semiconductor Company owned PHILIPS.
360 ° view of a \"bird\'s-eye\"
In the system implemented the technology which produces a seamless video from four cameras.
Four video integrated into one allowing all-round visibility of the car mode
real time, with no blind spots.
4-channel high-definition video
The system consists of four cameras that have high resolution, sensitivity
provides an overview at night, horizontal angle 180°. The system automatically
adjusts the video depending on the light.
cyclic Recording
Cyclic video recording in real-time, automatic start when you turn on Ignition Ia.
Video recording on the Micro-SD card (up to 32GB) or transfer to. Record with 4 cameras or any one choice.
3 Ways to activate the system and the video output to the monitor
1. video when parking - activates when reverse gear;
2. video and activation of the system with the remote control;
and system activation by double-clicking \"emergency light.\"
Product Parameters:
|
|
Unit |
Specification |
|
|
camera |
Image Sensor |
PC1089N |
|
|
Optical Size |
Inch |
1/3\" |
|
|
Pixel Pitch |
μm |
6.35um*7.4um |
|
|
Effective Pixels |
pixels |
720(H)*480(V) |
|
|
Horizontal Resolution |
TV Lines |
580 |
|
|
Video Format |
PAL / NTSC |
||
|
S/N Ratio |
dB |
＞48dB |
|
|
Dynamic range |
dB |
＞72dB |
|
|
Auto Electronic Exposure |
sec |
Electronic Rolling Shutter |
|
|
Minimum lllumination |
Lux |
0.1 |
|
|
View Angle |
Degree(°) |
180 |
|
|
Video output |
Vp-p |
1.0VP-P/75Ω |
|
|
host |
Supply Voltage |
V DC |
12V(8~30V) |
|
Consumption Current |
mA |
＜500 |
|
|
Operation Temperature |
℃/°F |
-20~75 |
|
|
Storge Temperature |
℃/°F |
-40~80 |
|
|
Waterproof level |
IP67 |
