Steel Billet Continuous Casting Machine LadleTurret With ISO Certification

FOB Price

Negotiable / Set

1 Set(Min.Order)

Supply Ability 0 Set / Sets per Month
Payment TermsT/T L/C D/P D/A
Delivery Detail7 days

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	HAIJUN		Place of Origin	China
Model Number	R4M 2 strand

Product Description

Delivery Time:2 month

Steel Billet Continuous Casting Machine LadleTurret With ISO Certification

Quick Detail:

CCM continuous casting machine radius: R4M Strand number :2 strands with ISO certification

Description:

We can produce high quality continuous casting machines from 1 to 8 strands with the lowest equipment manufacturing cost.We can design, manufacture the up-to-date billet continuous casting machine in accordance with the user\'s steelmaking capacity, billet size, steel grades and the user\'s field conditions.

Specification:

1. Basic standby technical parameters:

Steel billet casting machine radius	4m
Strand quantity	2 strands
Ladle support type	Ladle turret,Ladle car,ladle mounts
Tundish carriage	Semi-portal, cross sliding function
Casting method	Metering nozzle, open casting
Secondary cooling	Water cooling , 1 adjusting circuit
Withdrawal straightening machine	Totally 5 roller, progressive straightening
Roll table	Chain group centralized drive
Dummy bar	Rigid, with self-adapting dummy bar head
Billet cutting	Manual cutting
Billet conveying	Group centralized live roller table
Cooling bank type	Simple cooling bed

2. Technical process description and capacity of steel billet CCM

Induction furnace:

Nominal capacity	15T
Tap-to-tap cycle	60min
Furnace quantity	2set

Production capacity

Working days	330 days/year
Average number of daily furnace	24/day
Production capacity	100,000t/year

3. Casting speed, productivity and strand quantity

R4m radius casting machine can cast steel groups of different specifications, the maximum casting speed

is as follows:

Casting sectional area(mm)	80×80	100×100	120×120
Casting speed(m/min)	3.0	2.8	2.6

NO.	Billet size	Casting speed	hourly output (tons)	Daily output 24hour (tons)	Annual output(330days) (tons)
1	80×80	3.0m/min	7.42	178	58,766
2	100×100	2.8m/min	10.81	259.	85615
3	120×120	2.6m/min	15.69	377	124,266

The calculation results is the ideal state of the production, please according to own actual situation of

adjustment.

Steel grade

Casting grade(m/min)

Effective deformation rate(ε)

Allowable deformation
