IP 68 Grade Fiber Optic Joint Closure 3 in 3 Out 96 Fibers With 6 Round Ports
Certification:ISO
IP 68 Grade Fiber Optic Joint Closure 3 in 3 out 96 Fibers with 6 round ports
Quick Detail:
IP68 Dome type fiber optic splicing closure.6 round ports ;Max 4 trays and 96 cores;Suit for 8-20mm cables;buffer storge,6holder-tpr,Used for wall mounted,pole mounted,man hole,duct mounting and pipeline,direct buried..
Description:
1. Protection grade:IP68
2. Material:PP,ABS(new first hand raw material)
3. Number of cable ports: 6round ports
4. Maximum Trays: 4 trays
5. Maximum Cores:96(singlel core)
6. Dimension (HxD):430mm *130 mm
7. Package material:Carton
8. Weight:2.5-3.0Kg
9. Cable diameter range:8-20mm
10. Sealing way of cables:Heat shrinking
11. Quality warrenty:2 years
12. Life span:more than 25 years
13. buffer storge
Applications:
Aerial,Wall mounted,pole mounted,manhole,duct mounting,pipeline,direct buried..etc
Specifications:
| Model | No.of ports | Cable range |
Max trays |
Max Capacity | Dimensions |
| GJS20-DR02A-6port-6holder-tpr | 6 | 8-20mm | 4 | 9 6cores | 430×ф130mm |
Competitive Advantage:
Easy & fast installation with no special tools Superior sealing performance(free sample for testing) The closure can be repeatly used many times. The cables can be fixed from 3 points,safe and reliable Enough space for surplus fibers inside the closure Flexible branching for fibers loose leaf type of splice tray fixing,easy operation&maintain Modular fiber management systemPictures:
