Hot Sell Hydraulic Four-colum Plane Cutting Machine

Hot Sell Hydraulic Four-colum Plane Cutting Machine photo-1
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Jiangsu, China
Brand Name:
SUMON
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Place of Origin Jiangsu, China
Brand Name SUMON
Model Number XCLP3-800
Certification CE

Precise 4-column Clicking Press, High Quality Clicking Press,Clicking Press,Precise 4-column Clicking Press

 MORE CUTTING MACHINE CLICK FOLLOWS:

1. Hydraulic Swing Arm Cutting Press



2. ATOM Cutting Press



3. Hydraulic Plane Cutting Press



4. Hydraulic Traveling Head Cutting Press



5. Specialized Cutting Press



USE AND CHARACTER

The machine is suitable for cutting single layer or multiple layers of leather, rubber , plastic, plastic packing, textile products, textile products, chemical fiber and other materials by forming cutter.

  • The operation is labor-saving and simple, with low malfunction, strong cutting force and high cutting speed.
  • The mechanism of double oil cylinder and precise four-column automatic balancing connection rod can guarantee the same cutting depth of each cutting position.
  • When the cutting board is pressed downwards to contact the cutter, it carries out automatic and slow cutting to make no size error between the uppermost layer and lowermost layer of the cut materials.
  • Operation with both hands makes high safety.



TECHNICAL SPECIFICATION

Model

XCLP3-800

Maximum Cutting Force

800KN

Range between the Working Tables

50-200mm

Size of upper Rocker

750x1220mm

Size of lower Worktable

750x1600mm

Motor Power

5.5kW

Hydraulic Oil Quantity

320L



RELATED PRODUCTS

Precision Four-Column Hydraulic Plane Cutting Machine

Model

Maximum Cutting Force

XCLP3-300

300KN

XCLP3-350

350KN

XCLP3-500

500KN

XCLP3-600

600KN

XCLP3-800

800KN

XCLP3-1000

1000KN



CONTACTS

Name: Jerry chen

 Add: No. 7-7, Airport Road, Nanyang Economic Development Zone

Hot sell Hydraulic four-colum plane cutting machine



Remark: We can make the machine according to your specifically order, for example the color, the motor information ,the working table etc.



Hot sell Hydraulic four-colum plane cutting machineHot sell Hydraulic four-colum plane cutting machine





Our Hot Sale Cutting Machine: (Please click the picture to link the product.)





Hot sell Hydraulic four-colum plane cutting machineHot sell Hydraulic four-colum plane cutting machineHot sell Hydraulic four-colum plane cutting machineHot sell Hydraulic four-colum plane cutting machine



Hot sell Hydraulic four-colum plane cutting machineHot sell Hydraulic four-colum plane cutting machine
