SMD2835 T5 led tube 4ft for supermarket , transparant / frosted cover

Delivery Time:5-7 work days
Certification:CE,ROHS

SMD2835 T5 led tube 4ft for supermarket , transparant / frosted cover

Quick Detail:

1. power: 18W

2. Size:D16*1200mm

3. LM:1800

4. Color temp:2800-6500K

5. IP class:IP54

6. PF:0.97

7. Warranty:2 years

8. Work Temp: -30-45℃

9. power- supply efficiency : 85%-87%

Description:

Size: D16*1200mm

LED quantity(pcs): 120

LED angle: 120

color temp: 2800-6500K

cover type: transparant and frosted

lumen LM(per 6000k): 1800

life span: 50000H

work Temp: -30-45℃

power- supply efficiency : 85%-87%

PF value: 0.97 above

Specification:

Type	1.2m(4 feet)
Size	D16*1200mm
Led type	SMD2835
Led quantity	120
Voltage	85-277
PF	0.97
Power	18W
Ra	70-80
Led brand	Epistar

Product detail:

Our Package detail:

25pcs/carton

cartion Size: 1290*25*25

volume weight:15KG

Gross weight:6.8KG

the install procedure as below:

1.Installation:

Above picture is the installation diagram of led tube light.

The first two holes in the wall with the installation, the rubber plug plugged With self tapping screws fixing clip locking to rubber plug The lamp bracket alignment clamp force press press into place The yellow green line to ground, the other two lines received a live wire and a zero line The power plug into the lamp socket

2,Warning Note

Working Voltage: AC 85V～265V 50/60Hz. Do not exceed the operating voltage range. This product is prohibited material immersed in liquid. The tube is designed for moisture-proof use only. Don’t put it into water.

It’s normal that the device will delay starting 2 seconds due to carrier charging after the turning on

Applications:

This led tube has the widely use:

the most important use for the commercial lighting, just as the office, supermarket, parking, it will supply us

the same power but just use the one third of the traditional fluorescent tube, so it can help us save the

power for the commercial environment,

1.suppermarket:

2.Supermarket use:

Shipping:

Competitive advantages:

1. Al shell:

high quality aluminum Alloy ,safe and durable, sophisticated technology thermal conductivity is strong.

2. lamp base:

high quality PC material, good flam retardant performance, anti-aging do not change color, effectively

prevent oxidation of the electronic shock.

3. lamp shade:

Delicate and high quality PC lampshade, light transmittance as high as 98%, refraction light even high

degree of safety service life is long.

4. lamp bead:

led super bright light bead, avirulent environmental protection, high conversion rate, lamp bead uniform

distribution the heat better.

Certification:

FAQ:

Q: Nearly all LED tube T5 are the same exterior,how to tell quality?

A: Price and exterior.

Though LED lighting products are with same or similar exterior,due to raw material cost difference is big,poor quality are all poor housing exterior with short FINs and light weight.So prices are also low.

Besides,the driver exterior is also low-end with poor IC,MOS and capacitances.

Q:Does LED tube T5 really have 50,000 hours lifespan?

A:50,000 or longer lifespan is only theroy from lab test.But due to working enviroments are different from in lab,actual lifespan is only <=30,000hours.

Especially for LED high bays and LED floods,the power is very huge,and lots of heat cause LEDs junction temperature very high.And light decay will be higher than low power LED products.

Our LED tubes are in the market over 7 years,and according to feedbacks from our clients,nearly no faluire in 4-5 years.

Q:For same power,why different suppliers with different brightness?

A:Different chips,or same chip but different brightness version.The brightness will be different.But for same chip and same brightness version
