Shoe Automatic Cutting Machine

Shoe Automatic Cutting Machine thumbnail-1
Shoe Automatic Cutting Machine photo-1
US$ 100 - 8,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Jiangsu, China
Brand Name:
SUMON
Model Number:
HSD/Q500
Contact Supplier Request Quote Chat Now
Jiangsu Southocean Industrial Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Jiangsu, China
Brand Name SUMON
Model Number HSD/Q500

Specifications

HSD/Q500 automatic stepping feeding movable head type cutting machine,High Quality cutting machine,cutting machine HSD/Q500

HSD/Q500 automatic stepping feeding movable head type cutting machine

Specifications

Products of special specifications can be customized.Optional: cutting board micro-movement device.

USE ANDCHARACTERISTICS:



1. The machine is applicable to continuous cutting operation of nonmetal rolled    materials of same specifications and large batches by die cutter. For example:     used in such industries as football, volleyball, tennis and medicine etc.
2.  The servo motor is adopted to control the horizontal movement of cutting head, and the multilayer materials are clamped by the cylinder for stepping feeding. The   machine can automatically complete the cutting of materials and the displacement   distance of cutting head and feeding length can be accurately set, which has solved  the problem of inaccurate feeding and layering length of multilayer materials.
3.  The machine has various working modes such as inching, manual and automatic  etc. modes. The workers need only to pick up the finished materials, with labor  intensity reduced and work efficiency enhanced.
4. The machine has cutting modes of stagger, stagger blade reducing and die cutter   rotation etc., which can save 10%~15% of raw materials.
5. As the machine is controlled by microcomputer with high automation degree, only  one worker is required for the whole machine, so that the production efficiency can  be enhanced for 3-5 times and the power can be almost 1/3 saved.

6.  With special setting mechanism, and in conjunction with die cutter and cutting   depth setting, the travel adjustment is simple and accurate.
7.  Products of special specifications can be customized.Optional: cutting board micro-movement device.


TECHNICAL SPECIFICATION


   Model
HSD/Q250
HSD/Q250A
HSD/Q250B
HSD/Q500
HSD/Q500A
HSD/Q500B
Maximum cutting force
250KN
250KN
250KN
500KN
500KN
500KN
Working table(mm)
1800*500
2000*500
2200*500
1800*550
2000*550
2200*550
Size of travel head(mm)
500*500
500*500
500*500
550*550
550*550
550*550
Adjustable stroke(mm)
5-150
5-150
5-150
5-150
5-150
5-150
Motor power
2.2kw
2.2kw
2.2kw
4.0kw
4.0kw
4.0kw
Machine’s dimensions(mm)
2200*620*2000
2400*620*2000
2600*620*2000
2200*620*2000
2400*620*2000
2800*620*2000
   G.W
2300kg
2800kg
3500kg
3500kg
4200kg
5000kg
shoe automatic cutting machine
