Aluminum sheet Metal drywall Stud And Track Roll Forming Machine With Hydraulic Cutting

Roll forming main machine

1 unit

5 TONS Un-coiler

1 unit

PLC Control panel

2 unit

Hydraulic station

1 unit

cutting device

1 unit

Safety cover device

1 unit

Manual out table

2 unit

Coil Material

Thickness

0.55mm

Coil width

Depend on customer’s requires

Yield Strength

G250-550Mpa

Material

Galvanized sheet, steel sheet,Aluminum sheet

Decoiler / Uncoiler

Coil Width

Max. 600mm

I.D

410-520mm

O.D

Max. 1200mm

Capability

Max. 5tons

Decoiler type

Manual / Hydraulic/Automatic

Feeding & Leveling

Pinch feeding

1 Units ( 2 Rollers )

Cutting device

Cutting motion

Hydraulic Cutting/Manual Model Cutting/Fly Saw Cutting; post-Cutting ( cutting sheet after forming )

Cutting blades

Cr12Mov with heat treatment HRC58-62

Length Measuring

Automatic length measuring by encoder & PLC.

Cutting Tolerance

1.5mm(per 3m)

Roll Forming Machine

Forming Stations

10 Stations

Rectifying

1 unit

Roller material

GCr15 steel, heat treatment

Diameter of shaft

65mm

Shaft material

High grade 45# steel

Drive type

Chains

Forming speed

15m/min

Main power

7.5KW

Servo motor

1 Units

Driven System

Transmission by chains

Electrical control

PLC

/

Inverter

YASKAWA Brand or Custom-made

Touch screen

/

Operation type

Touch screen & Button

Hydraulic Station

Hydraulic station

Famous Chinese brand

Hydraulic power

5.5kw

Runout Table

Table type

Simple non-power type

Function

To support the finished panels

TOTAL WEIGHT

APRRO 4tons
