1.Smallcam and connecting rolling wheel transmission which is the most advancedtechnology is adopted,making it easy and stable to run.
2.Rollingtransmission is adopted in entire structure instead of slide block and slide rod,which does not need lubricant anddecreases the wearing part.
3.Baseband belt fromItalyis used,which is durable and will not break or be stretched.
4.Itcan be configured with automatically stop detecting unit when meeting thesituation of warp/weft breaking,weft ending.The stoppage unit is sensitive andreliable.
5.PLCcentralized control is adopted for electric controlling,as well,frequency speedregulation which is convenient and stable.
6.Itis high-efficient and energy economical.The highest rotation speed of the mainmotor can reach 180r/min and the power is 3kw.which can save 10 thousand degreeelectricity compared with the traditional small-sized six shuttle circular loomwhose power is 4kw.
Main technical parameter
Model |
S-YZJ-850/6S |
Number of shuttle |
6 |
Weaving folding width |
350-850 |
Max.number of warp |
720 |
Revolution of main motor |
120-180r/min |
Production capacity |
1.8-2.7m/min |
Power of main motor |
2.2/3kw |
Total power |
2.7/3.5kw |
Weight(about) |
3000kg |
Overall dimension(L*W*H) |
9100×2410×3100mm |
