Dongde brand SC200/200 builder's lift isprovided with reliable electric and mechanical interlocking safety device,withsafety switch,upper and lower limit switches,extreme limit switch,safetyprotection hook and other electromenchanical interlock switches.
  Advanced inching type anti-droppingsafety device,sensitive and reliable overload protection device and advancedcomputerized automatic shelving device are your best choice.
  Complete with imported original frequencyconversion speed governing system,high-quality motor and reducer,the liftingspeed is 0-36m/min,satisfying the requirements of all users.
Frequency conversion speed regulation builder'slift has the following characteristics:
1.Smooth starting and braking,without impact;
2.Lifing speed is adjustable by driver;
3.Starting current is smaller than ratedcurrent;
4.Low mechanical wearing.Impact-free startingallows low mechanical wear to gears and wears,especially to brake;
5.Remarkable energy saving effects.
Computerized automaitc shelving builder's lifthas the following characteristics:
1.Simple structure with single chipmicroprocessor controler,stroke waitch for signal input;
2.Dropping and rising back beforestop,overcoming the movement inertia by using the dead weight of cradle,makingthe maximum deviation less than 75px;
3.Protection against unauthorized operation;
4.Excellent interference free performance.

Type specification

Rated load(kg): 2*2000

Rated erection load(kg): 2*1000

Jib attachment rated load(kg):300/600

Cage size(m):3.0*1.3*2.4 3.0*1.5*2.4

Lifting speed(m/min):33

Rated output(kw):2*3*11

Rated frequency(Hz):50/60

Rated current(A):2*2*33.2

Voltage rating(V):~380±5﹪

Power supply fuses(A):2*96

Protective class:IP55

The durative rate of electrifying:FC-25﹪

Safety device(m/s):1.2

Snclosure weight(kg):1480

Cage weight(kg):2*2000

Mast section weight(kg):150/170/190/210

Mast section length(mm):1508
