Highly Pressure Accelerated Aging Test Chamber

Highly pressure accelerated aging test machine(PCT chamber) also know as PCT aging chamber, It is widely used to test the product air tightness and for some relevant product accelerated life test. It is used to quickly expose product flaws and weaknesses in the design stage.

Application:

Multi-layer circuit board, IC sealing package, LCD screen, LED, semi-conductor, magnetic materials, NdFeB, rare earths and magnet iron, plastics etc. Design standard: ASTM, DIN, BS, IEC, NACE, UL, CNS, ISO, JIS, MIL.

Specification

 Model: ZH-PCT-25/35/45/55

 Control system:Micro-computer saturated steam

 temperature + time + pressure display independent controller

Operating temp.:temp.range of Saturated Steam:100°C~132°C ( 143°C is per special ordered)

 Operating Humidity :100%RH saturated steam humidity

 Steam Pressure (Absolute Pressure):0.0Kg/cm2 ~ 4.0Kg/cm2;(secure pressure capacity 4kg/cm2 /G=1 environmental atmospheric pressure +3kg/cm2)

 Circular mode:Natural steam convective circulation
