Motor Drive Thermal Clad PCB , Metal Core PCB for Power Conversion



Product Name:

Thermal Clad  PCB

Material:

Metal Core

Layer Count:

1 Layer

Board Thickness:

1.5mm

Thermal Conductivity

2.0 w/mk

Surface Finish:

Immersion Gold

Original

China PCB Manufacturer

Applications:

Power Conversion



Descriptions:


Thermal clad metal core PCB is a unique layered system comprised of the follow layers:


Base Layer: usually aluminum could also be copper or iron alloy. Thickness from 0.5mm to 4.0mm, standard is 1.5mm


Circuit Layer: Copper foil with thickness of 1oz to 6 oz


Dielectric Layer: a layer of thermal insulation materials with low thermal resistancem


Thermal Clad Metal Core PCB applications


Power Conversion: Thermal clad PCB offers a variety of thermal performances, which is highly reliable and compatible with mechanical fastenersLEDs: Thermal clad PCB assures the lowest possible operating temperatures and maximum brightness, color and life.Motor Drives: Thermal clad PCB dielectric choices provide the electrical isolation meet operating parameters and safety agency test requirements.Solid State Relays: Thermal clad PCB offers a very thermally efficient and mechanically robust substrate.Automotive: The automotive industry uses thermal clad PCB boards as it needs long term reliability under high operating temperatures coupled with its requirement of effective space utilization.


Thermal Clad PCB Material

BergquistThermagonArlonDenka



Thermal Clad PCB Specifications


1 & 2 Layer DielectricsUp to 6 oz finished CuAluminum, Copper and iron alloy base material up to .250\" thickHASL, ENIG ,OSP, Pb Free HASL finishing available


Thermal Clad PCB Benefits


Lower Operating TemperaturesImproved Product DurabilityIncreased Power DensityIncreased Thermal EfficiencyReduced Number of InterconnectsLower Junction TemperaturesReduced PCB SizeEliminates Older HardwareMinimizes Labor Required for AssemblyWide Variety of Form FactorsMinimize Thermal Impedance


Thermal Clad Metal Core PCB fabrication contact us for more details.
