Modern Moveable Accents Holiday Home / Prefab Garden Studio For Holiday Living

Modern Moveable Accents Holiday Home / Prefab Garden Studio For Holiday Living

Quick Detail:

Description:

Main structure: Light Gauge Steel

Wall cladding: ALC panel/fibre cement cladding+MGO board/gypsum board

Insulation material: glass wool or also EPS/XPS/PU sandwich panel

Ceiling material: MGO board/gypsum board

Roof: EPS sandwich panel/steel roofing/asphalt shingle

Flooring: laminate flooring/wooden/PVC carpet

Door: steel security door/WPC or wooden door

Window: aluminum alloy/PVC

Other fittings: toilet,washbasin,shower,kitchen etc.

Life time: 100 years for structure

Applications:

toilet,washbasin,shower,kitchen,study room etc.

Specifications

Home accents holiday :

ISO standard light gauge steel for main structure.one or two also three floors available.fireproof,heat insulation,wind and earthquake resistance.green,energy save. economically.

Why Choose Light Gauge Steel Structure?

1)Lifetime for structure: 100 years.

2)Earthquake resistance: mix more than 8 grades.

3)Wind resistance:max 60m/s.

4)Fire resistance:all the materials used can be fire resistance.

5)Snow resistance:max 2.9KN/m²as required

6)Heat insulation:100 mm in thickness can match 1 m thickness of brick wall.

7)High acoustic insulation:60db of exterior wall 40db of interior wall

8)Insect prevention: Free from the damages by insects, such as white ants

9)Ventilation:a combination of natural ventilation or air supply keep the indoor air fresh and clean

10)Packing and delivery: 140SQM/ 40\'HQ container for structure only and 90SQM/ 40\'HQ container for structure with decorate materials.

11)Installation:the average is one worker one day install one SQM.

12)Installation guide:dispatch engineer to guide on site.

Design code:

(1)AISI S100 North American Specification for the Design of Cold Formed Steel Structural Members published by the American Iron and Steel Institute (AISI) in the United States.

(2)AS/NZS 4600 Australian/New Zealand Standard-Cold-formed steel structures jointly published by Standards Australia and Standards New Zealand.

(3)BS 5950-5 Structural use of steelwork in building-Part 5. Code of practice for design of cold formed thin gauge sections published by BSI in the UK.

(4)ENV1993-1-3 means Eurocode 3: Design of steel structures; Part 1.3: General rules, Supplementary rules for cold-formed thin gauge members.

Production in DeepBlue factory:

How The House Build:

Technology Details:

  Your first choice,Deepblue Prefabricated house in China.
