Wooden Style Modular Homes Bungalow / Sound-Proof Prefab Bungalow

 Wooden Style Modular Homes Bungalow / Sound-Proof Prefab Bungalow

Quick Detail:

Description:

Main structure: Light gauge steel frame

Standard: AS/NZ ,IBC

Wind Load: 50m/s

Snow load: 1.5KN/sqm

Earthquake load: 8 degree

Ceiling height:

Wall: Bamboo panel/wooden/WPC panel

Design: Based on request

Applications:

Hotel, House, Office, Villa ,etc

Specifications

Wooden cheap modular homes bungalow is based on light gauge steel frame system with high performance finishing materials. The whole house can be assembled within couple of hours by 4workers.

the materials are the following:

1. Main structure: 89mm light gauge steel framing system based on AS/NZS 4600 standard.

the structure can be design to resist 50m/s wind and 9degree earthquake.

2. Roof structure: 89mm light gauge steel truss system.

3. Chassis : 89mm light gauge steel flooring chassis

4. flooring: 18mm fiber cement board with vapor barrior and bamboo flooring or wooden flooring , pvc carpet etc.

5.Wall cladding: 16mm PU insulated steel sandwich panel with beautiful decoration

6. interior lining: 9m fiber cement board ,water-proof ,termite-proof ,security and healthy

7. ceiling: 8mm pvc ceiling panel

8. insulation: 89mm glasswool insulation with good sound proof performance.

dows: PVC sliding windows

10.exterior door: high quality aluminim sliding windows

11.interior door: painted wood door

12.bathroom: shower, wash basin, toilet inculded

13. roofing: corrugated steel roofing with gutter system

14. veranda deck: W.P.C veranda flooring.

ISO standard light gauge steel for main structure.fireproof,heat insulation,wind and earthquake resistance.green,energy save. also economically.

If You Need: prefabricated bungalow; prefab bungalow.

We Can Provide You:villa;bungalw;low cost house;granny flat;apartment etc.many buildings.

Only Need You To Provide Us these information:

your house area,how many floor,how many bedrooms,luxury or normally,or low cost configuation.

House building:

Why Choose Light Gauge Steel Structure?

1)Lifetime for structure: 100 years.

2)Earthquake resistance: mix more than 8 grades.

3)Wind resistance:max 60m/s.

4)Fire resistance:all the materials used can be fire resistance.

5)Snow resistance:max 2.9KN/m²as required

6)Heat insulation:100 mm in thickness can match 1 m thickness of brick wall.

7)High acoustic insulation:60db of exterior wall 40db of interior wall

8)Insect prevention: Free from the damages by insects, such as white ants

9)Ventilation:a combination of natural ventilation or air supply keep the indoor air fresh and clean

10)Packing and delivery: 140SQM/ 40\'HQ container for structure only and 90SQM/ 40\'HQ container for structure with decorate materials.

11)Installation:the average is one worker one day install one SQM.

12)Installation guide:dispatch engineer to guide on site.

Design code:

(1)AISI S100 North American Specification for the Design of Cold Formed Steel Structural Members published by the American Iron and Steel Institute (AISI) in the United States.

(2)AS/NZS 4600 Australian/New Zealand Standard-Cold-formed steel structures jointly published by Standards Australia and Standards New Zealand.

(3)BS 5950-5 Structural use of steelwork in building-Part 5. Code of practice for design of cold formed thin gauge sections published by BSI in the UK.

(4)ENV1993-1-3 means Eurocode 3: Design of steel structures; Part 1.3: General rul
