Rubber Membrane Keyboard Graphic Overlays For Human Machine interface

FOB Price

US$ 0.2 - 12 / Piece

1 Piece(Min. Order)

Payment TermsT/T L/C D/P D/A
Delivery Detail7 days

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	TianTai		Place of Origin	China
Model Number	TT-MS-037

Product Description

Delivery Time:Around 14-18 business days after payment
Certification:ISO9001:2008, SGS,Rohs

Rubber Membrane Switch Panel Graphic Overlays For Human Machine interface

Description:

Graphic overlay:

perfect exterior Autotype PC or PET overlay Finish: glossy or matt. Rear Adhesive: 3M467 or 3M468 Matching color:Pantone and RALcolor matching system. SMD welding or by hand welding as per request metal dome or polydome, assemble with silicone keypad is also available. Withstand millions of cycles Standard Tolerances: 0.10inch(0.25mm)

	Polyester	Polycarbonate
Mechanical Resistance	Very high	Poor
Chemical Resistance	High	Poor
Thermal Resistance	Acceptable	Good
Abrasion Resistance	High	Acceptable
UV Resistance	Available	Not Available
Fatigue resistance	Superior (to 1,000,000 cycles)	poor
Dielectric Property	High	Good
flexure	great	poor
lifespan	Very good	Good (100,000 key cycles)
Range of surface finishes	Average	High
Transparency	Average to High	High
Thickness	.008” and thinner	.005” to .300” (and thicker)
Flammability	Not Available	Available
texture	limited	From fine mattes to course velvets

Applications:

Our membrane switches are widely used in :

Human Machine interface Automatic Control Equipment Telecommunications apparatus Telephone systems Household appliances Security systems Industrial controller Access control systems.....

Specifications:

wire lead resistance:	＜1Ω/CM	Life time:	>1 Million times
rated current:	25-100mA,0～30V DC	Operation Temperature:	-40℃～70℃
Rated Voltage:	＜50V, DC	Operation Humidity:	at 40℃,＜98%RH
Insulation resistance:	＜100MΩ,250V DC	Dome springback time:	＜5 msec
Switch travel:	Flat Type 0.05-0.3mm	Base Material voltage withstand:	1500 V DC
tactile type:0.3-1.5mm	Tail flexiblility:	any angle within 180 degree
