Home > Industrial Equipment & Components > Boiler & Furnace > Boiler Parts > Electric Brushless DC Motor 6 Lead 22mm With 24 Volt and Three Phase

Electric Brushless DC Motor 6 Lead 22mm With 24 Volt and Three Phase

Changzhou Jingkong Mootor&electric Group

Electric Brushless DC Motor 6 Lead 22mm With 24 Volt and Three Phase photo-1

Negotiable MOQ: 1 Ton (Price negotiable depending on order volume and customization)

Key Specifications

Get Latest Price

Brand Name:

Place of Origin:

China

Model Number:

JK22RBL

Contact Supplier Request Quote Chat Now

Payment & Shipping

Payment Methods:

Port of Shipment:

China

Delivery Detail:

7 days

Product Details
Company Profile
Contact Us

Brand Name JK

Place of Origin China

Model Number JK22RBL

Delivery Time:FOR SAMPLES , 7-10 days For batch . 15-25days.
Certification:CE,ROHS ,ISO9001

Electric Brushless DC Motor 6 Lead 22mm with 24 Volt and three Phase

22BLDC motor Model Number:JK22RBL Phase: 3 Phase Lead Wire (No.): 4 or 6 wire Step Angle: 1.8°/ 0.9° Motor Height: 22mm Number of poles:8 Peak current :1.1 - 1.5 A Rated Voltage: 24 V Power: DC Peak Torque: 21 mN.m -50mN.m Function: Control Speed: Low or High speed Usage: Industrial Shape: Tubular Certification: CE, ROHS, ISO9001

22mm brushless dc motor /22BLDC motor/ Chinese supplier for brushless motor/

Description:

22mm brushless dc motor , BLDC MOTOR 24v dc brushless motor, 22mm dc brushless motor,

GENERAL SPECIFICATIONS	ELECTRIC CONNECTION
Winding type	Star
Hall effect angle	120 degree electrical angle
Shaft run out	0.025mm
Radial play	0.02mm@450g
End play	0.08mm@450g
Max. radial force	10N @ 10mm from the flange
Max. axial force	2N
Insulation class	Class B
Dielectric strength	500VDC for one minute
Insulation resistance	100MΩMin., 500VDC

Applications:

Use for CNC machine .

Electric Specifications:

Model	JK22RBL45	JK22RBL68
Number of poles	8	8
Number of phase	3	3
Rated voltage VDC	24	24
Rated speed RPM	4600	3500
Continuous stall torque mN.m	9.6	26.4
Rated torque mN.m	8	22
Rated power W	3.8	8
Peak torque mN.m	21	50
Peak current A	1.1	1.5
Line to line resistance ohms	23	11.8
Line to line inductance mH	6.2	4.2
Torque constant mNm/A	30.2	35.5
Rotor inertia g.cm2	0.66	1.32
Body length mm	45	68
Mass Kg	0.07	0.12
