LSX Series Sand Washing Machine
Zenith screw sand washing machine is mainly used for sand processing, electric pole factory, building work site and concrete dam, various sands classifying and dewatering. This sand washer adopts inclination of 15°, under the water tub, three weir plates form the sediment pool, the screw head is immersed in this pool, the screw is driven by electric motor through reducer rotating continuously, the fresh water is feeding from porous plate at bottom of sediment pool, this machine have three functions of washing, dewatering, classifying.
Features
1. Simple structure, transmission bearing of impeller depart from water and material.
2. The loss of fine sand occupy very small proportion.
3. No quick-wear part.
4. Long service life.
5. Reasonable structure, easy maintenance.
6. High capacity and cleanliness of sand.
Technical data
|
Model |
Screw Diameter (mm) |
Tank Length (mm) |
Screw Quantity |
Max Feeding (mm) |
Capacity (t/h) |
REV (r/min) |
Power (kw) |
Motor Model |
Water Consumption (t/h) |
Machine Size (mm) |
|
LSX920 |
920 |
7585 |
1 |
≤10 |
100 |
21 |
6-11 |
Y160L-6/11 |
10-80 |
8420×2180×3960 |
|
2LSX920 |
920 |
7580 |
2 |
≤10 |
200 |
21 |
6-11×2 |
Y160L-6/11 |
20-160 |
8420×3970×3960 |
|
LSX1120 |
1120 |
9750 |
1 |
≤10 |
175 |
17 |
6-18.5 |
Y200L1-6/18.5 |
20-150 |
10770×3950×4860 |
|
2LSX1120 |
1120 |
9750 |
2 |
≤10 |
350 |
17 |
6-18.5×2 |
Y200L1-6/18.5 |
40-300 |
10770×5260×4860 |
Zenith service
Pre-sales Service:
The wide product range enables us to provide our customers with individual machines or complete processing plants. Based on our customers’ request and budget, our experts make efficient, reliable solutions, and we produce strictly follow customers’ order. What’s more, every customer has the chance to visit the working machine in the site before placing the order.
Most of the visiting foreign customers feel inconvenient for the first time. Due to this condition, we help to arrange cars, hotels, and translators for every visiting customer.
After-sales Service:
Experienced technicians guidance is available on the phone, and on the internet. One or more engineers will be dispatched to the quarry site to help install the customers’ plants. Necessary training about machine daily maintenance to local workers is provided also.
After-Sales department is made of well-trained employees, and installation engineers. The installation technicians are special and professional team of Zenith; they are now strategically located home and abroad, working for our customers.
