Help Center1000m3/h, Medium Size Cryogenic Oxygen Plant , Oxygen Making Machine,air Separation Plant
Related Products
-
High Purity Cryogenic Oxygen Plant , 380V 50Hz Air Separation Plant,for Medical and Industrial UseNegotiableMOQ: 1 Piece -
Medical Cryogenic Oxygen Plant , Skid-mounted Liquid Oxygen Equipment for Medical and Industrial UseNegotiableMOQ: 1 Piece
-
Low Pressure Cryogenic Oxygen Plant , Nitrogen Generating Equipment,purity:99.9%-99.999%NegotiableMOQ: 1 Piece
-
Cryogenic Oxygen Plant , 99.7 % Purity Oxygen Generating Equipment,gas Filling Device,Internal ComprNegotiableMOQ: 1 Piece
-
2000m3/hour Oxygen Cylinder Filling Plant For Industrial and Medical,gas Filling DeviceNegotiableMOQ: 1 Meter
Certification:ISO 9001:2000
1000Kw Medium Size Cryogenic Oxygen Plant , Oxygen Making Machine
Quick Details:
Condition: new
Place of origin: China(mainland)
Brand name: UIG
Model number: KDON, KDONAr, SERIES
Production capacity:1000-6000 m3/hour
Power :1000-5000 KW
Voltage:380v,6000V,10000V
Certification: ISO 9001:2000
Warranty:1 year
Life:20 years with proper maintenance
After-sales service provided: Engineers available to service plants overseas
Usage: Industrial and medical (oxygen,liquid oxygen,nitrogen,liquid nitrogen,argon)
UIG Air separation plants are designed for a vast range of capacities and products summarized below: FOR OXYGEN 99.7 % ,NITROGEN 99.999% AND ARGON99.999%.
Specifications:
The main technical specifications of external compression
|
Model contents |
KDON- 1000-2000 |
KDON- 1500-3000 |
KDONAR- 3000-3000-90 |
KDONAR- 4500-4500-140 |
KDONAR- 6000-6000-200 |
|
|
Gox flow |
Nm³/h |
1000 |
1500 |
3000 |
4500 |
6000 |
|
Gox purity |
％(O2) |
99.6 |
99.6 |
99.6 |
99.6 |
99.6 |
|
Gan flow |
Nm³/h |
2000 |
3000 |
3000 |
4500 |
8000 |
|
Gan purity |
Ppm(O2) |
≤10 |
≤10 |
≤10 |
≤10 |
≤10 |
|
Ar flow |
Nm³/h |
90 |
140 |
200 |
||
|
Ar purity |
Ppm(O2) |
≤10 |
≤10 |
≤10 |
||
|
Operating pressure |
Mpa |
0.58 |
0.56 |
0.56 |
0.56 |
0.56 |
|
Start-up time |
hour(O2) |
≤22 |
≤22 |
≤24 |
≤26 |
≤30 |
|
Operating period |
year |
≥2 |
≥2 |
≥2 |
≥2 |
≥2 |
Oxygen booster with oxygen compressor.
Description:
•Feed air compression, pre-cooling and purification systems
Feed air from atmosphere is removed dust and mechanical impurity through air filter then enters into Air Compressor. Compressed air with pressure of 0.7Mpa(G) is sent into Air Pre-cooling System to be cooled down to 5~8°C.
Cooled air enters into Molecular Sieve Purification System for adsorption in where moistures, carbon dioxide, acetylene and other hydrocarbons impurities are removed. There are two alternative working vertical adsorbers. When one adsorber works another will be i
