stainless steel 304 48x 10 mesh Automatic Screen Filter Belt made in China
Filter Fineness: 300um,
Wire Diameter: 0.5 x0.5mm.
Weight : 3.6kg/sq.m
Materials : Steel Wire.
Width : 9.7cm. 10cm, 12cm. 12.7cm. 12.8cm. 13.3cm. 21cm. 23cm.
Length : 30M. 40m 20m. 10M.
MOQ : 3-10 rolls for your test the quality and strength.
Capacity : For 20 feet container within 30days.
Payment term: T/T. Western Union.
For mechanical machinery for advance plastic, chemical industry and chemical fiber industry.
Available in rolls as your specification
Custom designs are also available
Basic specifications
Mesh | Wire Dai.(mm) | Thickness(mm) | Width(cm) |
45x15 | 0.45x0.6 | 1.75 | 9.7-28 |
48X10 | 0.50X0.50 | 3.6kg/sq.m | 9.7-28 |
72x15 | 0.45x0.55 | 1.7 | 9.7-28 |
90X17 | 0.23X0.55 | 2.48kg/sq.m | 9.7-28 |
110X17 | 0.23X0.55 | 2.6kg/sq.m | 9.7-28 |
110X21 | 0.23X0.35 | 2.0kg/sq.m | 9.7-28 |
120x16 | 0.35x0.45 | 1.36 | 9.7-28 |
132x17 | 0. 3x0.45 | 1.3 | 9.7-28 |
152x24 | 0.3x0.40 | 1.2 | 9.7-28 |
160x18 | 0.28x0.45 | 1.27 | 8-85 |
200x40 | 0.15x0.27 | 0.7 | 8-130 |
260x40 | 0.15 x0.27 | 0.65 | 8-130 |
300x40 | 0.15 x0.27 | 0.65 | 8-130 |
360x40 | 0.13 x0.27 | 0.6 | 8-130 |
Special specification we can produce according to customers' requirements. | |||
A : Do you have stock or not ?
Yes , we have a lot of stock( 800rolls stock always ) ,fast delivery .
B: Do you accept small order -1 roll ?
Yes, surely , 1 roll is no problem for us .
C : Do you offer free sample for our testing ?
Yes , we surely offer free sample for your quality confirmation .
Automatic Screen Filter Belt Features:
With smooth surface, high hardness, working continuously, no deformation, high temperature resistance, corrosion resistance, flexible working with excellent filtering performance.
| Continuous automatic filter belt | |||
Mesh/inch | Wire Dia.(mm) | Width(mm) | Length/Roll(m) |
72/15 | 0.45/0.55 | 97---400 | 10/20 |
120/15 | 0.35/0.45 | 97---400 | 10/20 |
132/17 | 0.32/0.45 | 97---400 | 10/20 |
150/17 | 0.3/0.45 | 97---400 | 10/20 |
152/24 | 0.27/0.4 | 97---400 | 10/20 |
170/17 | 0.27/0.45 | 97---400 | 10/20 |
180/18 | 0.27/0.45 | 97---400 | 10/20 |
200/40 | 0.17/0.27 | 97---400 | 10/20 |
260/40 | 0.15/0.25 | 97---400 | 10/20 |
Other sizes are avaliable according to clients'request.
Edge of Automatic Screen Filter Belt ::
Applications of Automatic Screen Filter Belt :
High Tensile Warp wire for Auto-Screen changers used in the Plastic Extrusion Industry for PP, PE, ABS, PS, PMMA and other materials.
Packing of Automatic Screen Filter Belt :
Waterproof paper on each roll + carton / wooden case
Shipping of Automatic Screen Filter Belt :
By sea or By Air - Express , No problem for us .
Do you accept Paypal , west Union ?
Yes It is ok for us ,No problem .
Contact us : Ms Alisa Zhou
Mobile : +86 18730291422
E-mail :alisawiremesh@hotmail.com
Wechat:perfectme88
Whats app : same as above Mobile number .
