Rolling Mill Equipment , Continuous Casting Billet Production
One production outline
1. Billet specification: 125×125×6000,150×150×6000
2. Billet: common carbon steel
3. Production specification: rebar∮8 -∮32
4. Output: 150,000tons / year
Two Process
With 150 × 150 × 3000mm continuous casting billet production Φ8-Φ32mm twisted steel in the production process on a semi-continuous rolling method, the export line speed to be as large as 14m / s;Rolling need to cut with computer multi-length shear before going to in cooling bed , fast shear, can only meet the technical requirements.
Three process
Billet—→ transportation roller—→Φ550 bloomer—→∮350×4 IM unit(Ⅰ)—→∮350×4 IM unit(Ⅱ) —→∮300×4 four FM units—→flying shear—→Pinch Roll —→Step-type cooling bed cooling—→ scale cold shear—→packaging(double) and marking —→ measurement—→ storage
Four equipment quote
|
No. |
Name |
Quantity |
Height |
|
1 |
Loading roller |
3 |
18 |
|
2 |
Push billet machine |
1 |
12 |
|
3 |
Reheating furnace |
1 |
|
|
4 |
Baked roller |
1 |
12 |
|
5 |
Transportation roller |
2 |
13 |
|
6 |
Roller before machine |
2 |
24 |
|
7 |
Φ550 bloomer(3 rollers) |
1 |
156 |
|
Connection Machine A = 550 |
1 |
||
|
Reducer |
1 |
||
|
Connecting shaft, coupling |
1 |
||
|
8 |
Lift-downbench after machine |
1 |
18 |
|
9 |
Work roller after machine |
2 |
24 |
|
10 |
Bloomer output roller |
1 |
8 |
|
11 |
∮350×4 IM unit(Ⅰ) |
4 |
148 |
|
United reducer |
2 |
||
|
Reducer |
2 |
||
|
Connecting shaft, coupling |
6 |
||
|
12 |
Output run slot |
2 |
4 |
|
13 |
∮350×4 IM unit(Ⅱ) |
4 |
122 |
|
United reducer |
2 |
||
|
Connecting shaft, coupling |
6 |
||
|
14 |
∮300×4 FM unit |
4 |
96 |
|
United reducer |
2 |
||
|
Connectin |
