Sell Offshore Drilling

Model No.:HZ-01
Product Origin:China
Brand Name:
Price Terms:
Payment Terms:
Certification:
Description:Walking Submersible Drilling Platform for Working Depth 10m Introduction: This platform is steel, non-propelled and mat support walking submersible drilling platform, it is mainly constructed by two parts: main platform and walking External Pontoon, and also can walk in the tidal land. The main platform is constructed by the hurricane deck, mat and element pillar system. This platform equips with helicopter deck and can suit for working in argillo-arenaceous submarine offshore area or the similar offshore area such as the river mouth, swamp land, tidal land and neritic area. Principle Parameter 1: Total LengthxWidth: 76mx43m; Upper deck: LengthxWidth: 52mx28m; 2: External Pontoon LengthxWidthxDepth: 72mx42mx3.0m; 3: Internal Pontoon LengthxWidthxDepth: 52mx28mx3.0m; 4: The height of main deck: 15m; 5: Walking speed of platform: 60∼100m/h; 6: Drilling chase (LengthxWidth): 12mx6m; 7: Derrick movement: Vertical: 5m; 8: Drilling capacity: 7000m, 41/2 in drilling pipe electrical Drilling Rig 9: Lifting capacity: 35tx32m ( Two); 10: Working depth of the platform 3m∼10m; 11: Light Draft of the Platform 2.5m 12:Operating Environmental Temperature: -10oC ∼ +40oC 13: Fixed No. of staff: 90 persons; 14: Self-sustaining Capacity: 20 days; 15: Service life-span: 20 years
