DOP Hepa Filter With Hood by H13 H14

DOP Hepa Filter With Hood by H13 H14 thumbnail-1
DOP Hepa Filter With Hood by H13 H14 thumbnail-2
DOP Hepa Filter With Hood by H13 H14 thumbnail-3
DOP Hepa Filter With Hood by H13 H14 photo-1
DOP Hepa Filter With Hood by H13 H14 photo-2
DOP Hepa Filter With Hood by H13 H14 photo-3
US$ 38 - 38 MOQ: 10 Sets
Key Specifications
Get Latest Price
Brand Name:
Longwell
Place of Origin:
China
Model Number:
HF
Contact Supplier Request Quote Chat Now
Guangzhou Longwell Air Filtech Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
7 days

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name Longwell
Place of Origin China
Model Number HF

Quick Details

  • Condition: New

  • Efficiency: H13-H15

  • Construction: Box Filter

  • Filtration Grade: Ulpa Filter

  • Medium Material: Fiberglass

  • Porosity: 0

  • fire proof: 100%

  • types: separator pleated

  • Dimension(L*W*H): 610*610*295mm

  • Weight: 5

  • Certification: ISO SGS CE

  • Warranty: 360days

  • After-sales Service Provided: Overseas third-party support available


Advantages

 Fine fiber ensures that filter maintains its efficiency throughout its life in the system

 High dust holding capacity

 Suitable for variable airflow

 Robust design



Description: High efficiency box style air filter with wet-laid paper style media in an all-metal enclosing frame.



Application: Built-up filter banks,rooftops,split systems,free-standing units, package systems and air handlers.



Type: Rigid pleated filter



Frame: Galvanised steel.



Media: Microfine Glass media formed into full pack depth pleats separated by corrugated aluminum separators.Or paper separator.



Gasket: Neoprene air inlet



Recommended final pressure drop: 450 Pa



Temperature: 70.C Max. in continuous service.



Fire rating: UL900.





SPECIFICATION:



Type

Dimension

(WxHxD)inch

Air flow

(m3/h)

Media area/(m2)

Dust holding/(g)

Initial resistance

(by 0.5m/s)/Pa

Final  resistance/Pa

Efficiency/0.3µ

HP-10

19 x 19 x 4.7

390

4.4

230

≤200

400

HP-11

24 x 24 x 4.7

620

7.1

370

≤200

400

HP-12

36 x 24 x 4.7

930

10.6

560

≤200

400

HP-13

48 x 24 x 4.7

1500

14.1

740

≤200

400

HP-14

19 x 19 x 5.9

530

6.0

320

≤200

400

≥99.97%

HP-15

24 x 24 x 5.9

1000

9.7

510

≤200

400

HP-16

36 x 24 x 5.9

1500

14.5

770

≤200

400

HP-17

48 x 24 x 5.9

2000

19.3

1020

≤200

400

HP-18

19 x 19 x 8.66

1000

9.8

600

≤200

400

HP-19

24 x 24 x  8.66

1600

15.8

920

≤200

400

HP-20

36 x 24 x  8.66

2300

23.7

1340

≤200

400

HP-21

48 x 24 x 8.66

3000

31.6

1750

≤200

400
