Heat Conducting 24KW Oil Furnace Temperature Control Unit Machine for Extruder

Delivery Time:20 – 35 work days
Certification:CE & ISO9001:2000

Heat Conducting 24KW Oil Furnace Temperature Control Unit Machine for Extruder

Quick Detail:

1. Thermometer for return oil

2. Automatic air-exhausting function after startup

3. Negative-pressure system(optional)

4. Certification:CE & ISO

5. Pump pressure:2.8Kg/cm2

6. Pump power: 1.5KW

7. RS485 communication function for automated management(optional)

Description:

Explosion-proof isolated electrical box Electric box external charged accessories explosion-proof Explosion-proof equipment Air blowing and return oil function(optional) Thermometer for return oil Automatic air-exhausting function after startup Switchover of heating power Negative-pressure system(optional) RS485 communication function for automated management(optional) Delay cooling shut-down function(optional) BY-PASS pressure release loop for hot oil Customizable multi-point temperature control unit Customizable horsepower and heating power of oil pump Brands OMRON, FUJI, TE, LG, MOELLER, ABB, and WEST for electric appliances Range of temperature control: +25℃-300℃ for incoming water CE certificate Stainless steel integrated pipelines for less pipe resistance and rust Control mode: imported microcomputer or PLC(optional) Perfect safety protection, fault display, easy repair and maintenance even free of professionals

Specifications:

ITEM	UNIT	AEOT-20BF-24
Temp control range	℃	Normal temp-300℃
Temp control accuracy	℃	PID±1℃
Power supply		AC3∮380V(3Phase+Earth)
Heat transfer medium		Thermo conductive oil
Cooling method		Indirect Cooling
Expansion Tank	L	67.5
Heating capacity	KW	18,24
Pump power	KW	1.5
Pump flow	M3/h	6.5
Pump pressure	Kg/cm2	2.8
Max. power consumption	KW	25.5
Alarm function		Pump reversal/Oil shortage/Overheating/Overload/Oil spill/Abnormal heating alarm/trip power outage
Cooling water pipe	inch	1/2
Circulating oil pipe	inch	1
Size(L×W×H)	mm	2100×600×1350
Heat pipe size/ length+ flange outer diameter	L×φ	1600×φ340

Competitive Advantage:

1. Strict quality control system

2. Three factories in shenzhen, tianjin and suzhou. More than 60 offices in China.

3. Our product is environmental and energy-saving

4. We have the production certification organic heat transfer material heater

5. High density heat insulation cotton and aluminum foil

6. Electric appliances brands:OMRON, JUJI, TE.LG, MOLLER, ABB and WEST

7. Imported microcomputer or PLC

8. Customization thick copper pipe 1.0-1.2

Applications:

Chemical Industry, Food Industry, Western medicine
