GB Standard Electric Round Aluminum Rod ACSR Wire & Cable or Can Custom
- T/T L/C D/P D/A
- 7 days
You May Like
-
Enterprise Standard Heat - Resistance Fire - Proof Cable 0.6 / 1kv for Power Transmission
-
Cu Core Fire - Proof & Insulation Layer Steel Wire Armored Heat-resistance Wire
-
GB Standard Insulation Layer Steel Wire Armored Heat - Resistance Fire - Proof Cable 1kv
-
GB Cu Core Fire - Proof & Insulation Layer Steel Tape Armored Heat-resistance Wire
-
IEC60331 Heat-resistance Wire and Fire - Proof Cable Rated A.C. Voltage 0.6 / 1kv
-
Enterprise Standard Insulation Layer Heat - Resistance Shield Fire - Proof Cable 0.6 / 1kv
Product Details
Brand Name | ZHONGDIAN | Place of Origin | China | |
Model Number | ZHONGDIAN |
Product Description
Certification:ISO 9001:2008, TLC, CCC
■ Product standard: GB/T3954-2001
According to the requirement of wide customer our company can produce aluminum
single wire and bared wire, etc
with any specification.
■ Type, status and specification
Type |
Status |
Diameter mm |
A2 A4 A6 A8 |
H112 |
9.5±0.5 |
Mechanical and electric property of aluminum rod
Type |
MPa Tensile resistance |
% Rate of elongation≥ |
20℃nΩ·m D.C. resistance≤ |
A2 |
80~110 |
12 |
27.85 |
A4 |
95~115 |
10 |
28.01 |
A6 |
110~130 |
8 |
28.01 |
A8 |
120~150 |
6 |
28.01 |
■ Diameter deviation
Diameter deviation of electric round aluminum rod and the elasticity should be in
conformity with the regulations in following list:
Diameter |
Error |
Elasticity not more than |
9.0~12.0 |
±0.5 |
0.9 |
13.5~20.0 |
±0.7 |
1.2 |
Note: The elasticity is the difference between Max diameter and Min diameter measured at same cross section while aluminum rod is perpendicular to axial line.
■ Surface quality
1. Electric round aluminum rod should be round and the size should be uniform.
2. The surface of electric round aluminum rod should be clean, without defects such as wrinkle, stagger round, crack, impurity, kink, etc as well as other defect that is harmful to application. The light mechanical scratch, spot, pit, peeling or black spot, etc are permitted.
■ Delivery weight
1. Electric round aluminum rod should be delivered by reel. Each reel will be over 1000kg.
2. According to the agreement signed by both parties, electric round aluminum rod with any weight can be delivered.
