Vertical Profile Section Bending Machine For Cylinder Workpiece In Oil Industry

FOB Price

Negotiable / Set

1 Set(Min. Order)

Payment TermsT/T L/C D/P D/A
Delivery Detail7 days

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	Pyramid		Place of Origin	China
Model Number	HFHJ-series

Product Description

Delivery Time:25-35days
Certification:CE,ISO,TUV

Vertical Profile Section Bending Machine For Cylinder Workpiece In Oil Industry

Quick Detail:

Name: Profile bending machine. Brand:Pyramid Usage:bending the steel profile from plat to arc

Description:
The arc down-adjusting 3-roller profile bending machine is from principle of the three points making circle, it is the special-purpose equipment for bending the steel profile from plat to arc, cylinder workpiece and special-purpose equipment for profile bending.

Applications:

It can bend round, arc shape widely used in oil, chemical industry, shipbuilding, steel structure and mechanical manufacture industries.

Specification

JW-	50S	75S	89S	115S	159S	245S	273S
(mm ) Profile section modulus of bending	6	16	30	45	100	320	500
(MPa) profile yield limit(MPa)	245	245	245	245	245	245	245
Steel pipe ◎ ∣ ◎	Max section	Φ42×3	Φ76×4	Φ89×5	Φ114×5	Φ159×5	Φ245×8	Φ273×10
Min bending Dia	φ500	φ800	φ1000	φ1250	φ1600	φ3500	φ5000
angle steel incurvature ┏ ∣ ┑	Max section	45×45×5	70×70×8	75×75×10	100×100×12	110×110×14	180×180×16	200×200×24
Min bending Dia	φ700	φ1100	φ1200	φ1300	φ1600	φ3600	φ4200
angle steel excurvature ┒ ∣ ┎	Max section	50×50×6	75×75×10	90×90×10	100×100×16	120×120×16	180×180×16	200×200×24
Min bending Dia	φ700	φ1000	φ1150	φ1300	φ1600	φ3500	φ42000
channel steel incurvature [ ∣ ]	Channel steel model	8	14	16
