Home > Products > Desktop Power Adapter > DC 12V 5A 60W Lenovo T61 Desktop Power Adapter ESD / EN61000 3-3 Black

DC 12V 5A 60W Lenovo T61 Desktop Power Adapter ESD / EN61000 3-3 Black

FOB Price

Negotiable / Carton

1 Carton(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	STARWELL		Place of Origin	China
Model Number	SW-00120500-S10

Delivery Time:10-15 days
Certification:UL,CE,ROHS, FCC,GS,SAA,C-TICK

DC 12V 5A 60W Lenovo T61 Desktop Power Adapter ESD / EN61000 3-3 Black

Feature:

> input voltage range: 100~240VAC

> output: 12V 5A

> Effiency: 85% minimum

> Ripple and Noise: 80mV maximum

> Color: Black or white

> Dc cable length: 1.5 meters

> DC jack: 5.5*2.1*10mm

> Net Weight: 250g

> Dimension:110(H)*51.5(W)*33.5(H)mm

> AC inlet: C8, C6, C14 optional

> Safety protection: over load, over voltage, short ciruict, open load protection.

Specifications

Input Rated Voltage :	100Vac~240Vac
Input Frequency Range:	47Hz~63Hz
Input Inrush Current :	0.8A max
Efficiency :	85%(MIN)at Rated Voltage
Output:	12V 5A
Output power :	60W
Ripple and Noise :	<150Mv at full road with 20MHz bandwidth
Turn On Delay Time:	<3S (AC:110V and full load)
Safety protection :	over voltage and current protection.
Leakage Current:	<5mA
USB connector:	5.52.110mm
Operating Temperature:	0°C----+60°C
Storage Temperature:	-20°C----+85°C
Certificate:	CE GS TUV UL/CUL FCC ROHS,SAA,PSE,C-TICK
Safety Standard :	EN60950-1 UL60950-1 ESD (EN61000 3-3) CAS (60950 ITE/TE) FCC Part 15 subpart B Class B AN/NZS CISPR 22:2006

MODEL LIST:
