Help CenterCar Reverse Parking Waterproof 12V HD Honda Rear View Camera With 3030 / 1089 Chip
Related Products
-
Night Vision Honda Rear View Camera , Backup Cameras For Vehicles 0.5Lux ~ 0.6LuxNegotiableMOQ: 1 Piece -
Mini 800 TVL CCD 170 Degree Honda Rear View Camera With LEDS for CivicNegotiableMOQ: 1 Piece
-
PAL / NTSC Car Honda 2008 Accord / City Rear View Back Up Camera ReliabilityNegotiableMOQ: 1 Piece
-
IP67 Water Proof Car Honda Accord Rear View Camera Wide Angle , 30 FpsNegotiableMOQ: 1 Piece
-
DC 12V High Definition Honda Rear View Camera / CCD Sensor , Shockproof 480TVL / 720TVLNegotiableMOQ: 1 Piece
Certification:CE, FCC
Car Reverse Parking Waterproof 12V HD Honda Rear View Camera with 3030 / 1089 Chip
Quick Detail
Special Type : Honda 2010 Odyssey
TV System: PAL / NTSC
Chipset : 3030 / 1089 / 7366 / 7959
Image Resolution : 720 TV L / 480TV lines
Lens Angle:170°
Lens: f = 2.5 mm, F = 2.0
Power Supply: DC 12 V
Working Current : 110 mA
White Balance / AGC / BLC : Auto
Description
1. Storage Temperature : -30°C~85°C, ( RH 95% MAX. )
2 . Working Temperature : -20°C~70°C , ( RH 95% MAX )
3 . Image quality assurance temperature : -20-+70 ℃
4 . Lens Angle : 170°
5 . Lens: f = 2.5 mm, F = 2.0
6 . Scanning System : 525lines , 60 fields/Sec (2:1 Interlace)
7 . TV System: PAL / NTSC
8 . Sync. System: Internal
9 . Sensing Area : 3.6mm x 2.7mm
10 . Video Output:1.0vp-p, 75 Ohm
11 . AGC : Auto
12 . BLC : Auto
13 . White Balance : Auto
14 . Current Consumption: 110 mA
15 . Power Supply: DC 12 V
16 . S/N Ratio: Better than 48 dB
17 . Frame Frequency : 30fps
18 . Connection : RCA / 4 PIN DIN
19 . Effective pixels : 648 x 488 pixels
20 . Shutter Speed : 1/50(PAL)/～1/100,000 S ,1/60(NTSC)～1/100,000 S
Connection : RCA / 4 PIN DIN
Help Parking and Reversing
Model Number : Honda 2010 Odyssey
Connect to the display of car or add a rear view mirror display
Specifications
Model Number : Honda 2010 Odyssey
| Waterproof of grade | IP68 |
| Voltage | DC12V |
| Working Current | 150 mA |
| Mininum illumination | 0.5 Lux (day) , 0 Lux (with IR) |
| Signal System | PAL/NTSC |
| Connection | RCA / 4 PIN DIN |
| Material | Plastic |
| Exposure Control | Auto |
| Gain Control | Auto |
| S/N Ratio | Better than 48 dB |
| Certificates | CE / FCC |
| Packaging | Gift Box / White Box |
| Anti-vibration | 10 g |
| Photosensitive Pixels | 648 * 488 Pixels / 962 * 504 Pixels |
| Image Feature | Level ( Horizontal ) |
| Horizontal Field angle | 115 ° |
Competitive advantages:
4 PIN DIN
High Definition
CCD , With Led
Night Vision
170 Degree Angle Lens
Auto BLC / AGC
