Help CenterMini 800 TVL CCD 170 Degree Honda Rear View Camera With LEDS for Civic
Related Products
-
PAL / NTSC Car Honda 2008 Accord / City Rear View Back Up Camera ReliabilityNegotiableMOQ: 1 Piece -
IP67 Water Proof Car Honda Accord Rear View Camera Wide Angle , 30 FpsNegotiableMOQ: 1 Piece
-
DC 12V High Definition Honda Rear View Camera / CCD Sensor , Shockproof 480TVL / 720TVLNegotiableMOQ: 1 Piece
-
170Parking and Reversing Honda Night Vision Rear View Back up Camera for AutoNegotiableMOQ: 1 Set
-
150mA Power Waterproof IP68 Honda Civic Rear View Camera With Night VisionNegotiableMOQ: 1
Certification:CE, FCC
Mini 800 TVL CCD 170 degree Honda Rear View Camera With LEDS for Civic
Quick Detail
Type : Honda Rear View Camera Chipset : PC7070 / 3030 / 3089 Camera Resolution : 800TVL TV System : PAL / NTSC Effective Pixels : 962 * 504 Pixels Sensing Area : 3.6 mm * 2.7 mm Power Supply : DC 12V Working Current : 110 mA Lens Angle : 170° Features : HD , Night Vision , Waterproof , Dustproof , CCDApplications
Lens : 170 degree
Camera Helping Parking and Reversing
Model Number : Honda 2010 Civic
Connect to the display of car or add a rear view mirror display
Description
1. Sensor: 1030 / 7070 / 1089 / 3089
2 . TV System: PAL / NTSC
3 . Scanning System : 2:1 Interlace
4 . Minimum Illumination : 0.5Lux
5 . Resolution:480TV / 720TV Lines
6 . Sensing Area (mm): 3.6 x 2.7
7 . Anti-vibration:10 g
8 . Effective Pixels : 648 x 488 pixels
9 . Sync. System: Internal
10 . Current Consumption: 110 mA
11 . Power Supply: DC 12 V
12 . Video Output:1.0vp-p, 75 Ohm
13 . S/N Ratio: Better than 48 dB
14 . White Balance/BLC/AGC: Auto
15 . Electronic Shutter : 1/50(PAL)/～1/100,000 S ,1/60(NTSC)～1/100,000 S
Specifications
| Connection | RCA / 4 PIN DIN |
| Sinal System | 1.0vp-p, 75 Ohm |
| Frame Frequency | 30fps |
| Scanning System | 525lines , 60 fields/Sec (2:1 Interlace) |
| Lens Angle | 170° |
| Image quality assurance temperature | -20-+70 ℃ |
| Working Temperature | -20°C~70°C , ( RH 95% MAX ) |
| Storage Temperature | -30°C~85°C, ( RH 95% MAX. ) |
| Working Current | 150mA |
| Voltage | DC 12V |
Competitive advantages
High Definition
CCD
Night Vision
Competitive Price
With LEDS
