Coarse Powder Mill
Negotiable
MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Brand Name:
LIMING
Place of Origin:
China
Model Number:
MSB1004
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
7 days
Related Products
Brand Name
LIMING
Place of Origin
China
Model Number
MSB1004
MSB Series Coarse Powder Mill is a kind of new high-tech milling machine to meet the requirements of sand processing customers. Based on our experts several years research experience in the milling industry and considering recommendations and requirements of domestic and foreign clients, it is the ideal equipment to replace Raymond Mill, mill, ball mill, and other traditional which only process power materials. It is high-efficiency equipment and widely applied in quartz sand, silica sand, foundry sand, fine sand and other sand abrasive industry. By being a component of closed production lines, it can produce various size products of better effect.
Working Principle:
Step with main shaft, bulk disk and roller bracket is driven by motor through reducer. Installed above bracket, roller assembly rotates with main shaft and swings freely meantime, this bring a large centrifugal force, which scatters bulk materials evenly in grinding intermediate layer between central roller and ring. The bulk materials are grinded into powder and fall on the bottom, and then discharged from discharging opening under the effect of synchronously-rotating scraper.
Main Performance Parameters:
Model: MSB1004
Roller quantity: 4pcs
Max. feeding size: <30mm Too hard material<20mm
Product size : 70-90%<2mm
Capacity: 8-15ton/hour Relative to average size and hardness of feeding material
Main motor power: 37-45kW Use small motor if use fine material and want low capacity
Main motor model: Y2-225M-4 45 kW
Overall size(L×W×H): 1.87×1.5×2.58(m) Including main motor, decelerator and main unit
Largest single pc weight: 900kg
Total weight(excluding electricity control cabinet) 8ton
Working Principle:
Step with main shaft, bulk disk and roller bracket is driven by motor through reducer. Installed above bracket, roller assembly rotates with main shaft and swings freely meantime, this bring a large centrifugal force, which scatters bulk materials evenly in grinding intermediate layer between central roller and ring. The bulk materials are grinded into powder and fall on the bottom, and then discharged from discharging opening under the effect of synchronously-rotating scraper.
Main Performance Parameters:
Model: MSB1004
Roller quantity: 4pcs
Max. feeding size: <30mm Too hard material<20mm
Product size : 70-90%<2mm
Capacity: 8-15ton/hour Relative to average size and hardness of feeding material
Main motor power: 37-45kW Use small motor if use fine material and want low capacity
Main motor model: Y2-225M-4 45 kW
Overall size(L×W×H): 1.87×1.5×2.58(m) Including main motor, decelerator and main unit
Largest single pc weight: 900kg
Total weight(excluding electricity control cabinet) 8ton
