Full Automatic 3 in 1 Water Filling Machine 20000bph For HDPE Bottle

Delivery Time:30 days
Certification:CE,SGS

Full Automatic 3 in 1 Water Filling Machine 20000bph For HDPE Bottle

Quick Detail:

1. Product: CGF40-40-12 water filling plant

2. Model:CGF40-40-12

3. Main Material: SS304

4. Production capacity: 20000bph(500ml)

5. Usage: Fill pure/mineral/distilled water and so on

6. Dimension: 4000*2200*2500mm

7. Warranty: 1year free

CGF40-40-12 water filling plant

Description:

Detailed Description:

(1) Water filling machine/packaging machinery includes: Washing-filling-capping 3 in 1 machine, lamp inspection, label shrinking machine, inkjet printer, hot shrink film packer and conveyors. It is a full automatic production line.

(2)The water filling machine is mainly used in the beverage filling operations. The three functions of bottle wash fill and seal are composed in one body of the machine. The whole process is automatic.

(3)The machine is used in filling juices, mineral water and purified water in bottles made of polyester and plastics. The machine can also be used in hot filling if being installed with temperature controlling device. The handle of the machine can be freely and conveniently turned to adjust the machine to fill various types of bottles.

(4)The filling operation is faster and more stable because the micro pressure filling operation of the new type is adopted. There the output and benefit of the machine is higher than the machinery of the same specifications.

(5)The advanced OMRON programmed controller (PLC) is adopted to control the machine to run automatically while a transducer is used in the bottle -entering chains to adjust speeds and coordinated with the transducer of the main machine to make the operations of moving bottle forward steadily and reliably.

(6)It is convenient to operate with higher automation because every part of the machine is inspected to run with photo electricity, On the bases, the filling parts of the machine can be changed into filling methods of lower vacuum.

(7)The filling category of lower vacuum (Z type machine) is applicable in glass bottles, filling alcohol, soy and such like materials. The aluminum theft proof cap and plastic cap can be adopted. The machine is idea-preferred equipment for beverage makers.

Application:

This machine is designed for bottling non-air drinks, such as pure water, mineral water etc, it
integrates bottle washing, filling and capping into one monobloc unit.

Specifications:

1) Feature

The CGF40-40-12 water filling plant adpots advanced human-machine interface control. High quality international name brand key components Suspension bottle neck catcher structure allows the machine change the bottle type easily. By changing the valves, it also can be used as hot filling machine Spring type rinsing catcher can wash both inside and outside of the bottle High accuracy pressure water filling mechanism, ensure the height and quatity of the water filling Magnetic powered cap device ensures tightness and prevents damage of the caps Quiet, rotary cap unscrambler will not damage caps. Photoelectric sensor detect missing caps thus eliminating uncapped bottle spillage Built-in safeguard mechanism ensures the safety of operator and machine. High efficient air clean filter system ensures high sanitary requirements Low overall machine noise Self-lubricating system imported from America provides continuous smooth operation

2) Technical parameter

Model	CGF40-40-12
Material	SS304
Pump	Nanfang(China famous brand)
PLC	Mitsubishi
Frequency converter	MITSUBI
Washing head	40pcs
Filling head	40pcs
Capping head	12pcs
Water consumption for bottle	10000kg/h
Total power	9.63kw
Total weight	8000kg

3) Pictures:
