Universal Wall Mount Battery Charger 30W 24V 0.8A , 100V AC - 240V AC

Name: Universal Wall Mount Battery Charger 30W 24V 0.8A , 100V AC - 240V AC
Brand: Panfore
SKU: 148942052
Availability: InStock

Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)

Key Specifications

Brand Name:

Panfore

Place of Origin:

China

Model Number:

BC240W0800E

Panfore Limited

Payment & Shipping

Payment Methods:

Port of Shipment:

China

Delivery Detail:

7 days

Brand Name Panfore

Place of Origin China

Model Number BC240W0800E

Delivery Time:15 days
Certification:CE,ROHS,REACH

Universal Wall Mount Battery charger 30W 24V 0.8A , 100V AC - 240V AC

Feature:

. Universal AC Input

. Detached AC plug: UK,CE,UL,SAA

. Class II power (Without Earth Pin)

. Protections: Overload, Short Circuit

. Approved By CE

. 2 Years Warranty

Description:

30W 24V800mA Interchangeable Plugs Wall Mount Battery charger

Electronics Specification :
Normal Input Voltage :	100-240Vac
Input Voltage Range :	90 – 264Vac
Input Frequency :	50/60Hz
AC Input Current :	0.7A at Full Load and any Input Voltage
Normal Output Voltage :	24.0Vdc
Maximum Output Current :	0.80±0.08A
Float Output Voltage:	27.6 ± 0.3Vdc (Green LED ON)
Half Load Voltage:	29.4± 0.3Vdc (Orange LED ON)
Bulk charge mode Voltage:	28~30Vdc (Orange LED ON)
Maximum Output wattage:	24.00W(At 0.8A load and any line)
Line Regulation :	±1% Maximum
Load Regulation :	±5% Maximum
Efficiency :	＞70%
Output Short Circuit Protection :	Can be Shorted without damage and auto recovery.
Environment :
Working Temp.:	0~40℃
Working Humidity:	20%~90% RH non-condensing
Storage Temp. & Humidity:	20℃~85℃, 10%~95% RH
Reliability :
Hi-Pot Testing Voltage :	I/P to O/P : 3.0 (60Sec.) KVac
Safety Standard :	EN60335-2-29
EMI Standard :	EN55022B
Mechanical Characteristics :
Case Size :	(L)94(W)50(H)33.5mm
Input Connector :	Interchangeable UK,CE,UL,SAA plug
Output Cable :	1.5M
Output Connector :	Red and Black clip
Safety Approval :
Certificate:	CE
