Detachable Blue Narrow Aisle Pallet Racking , 1tons/layer Metal Storage Shelves
Quick Detail:
● Mechanical Handling Equipment
● Specialist high cost machine-requires good floor surface.
● Operates within guide rails or wire induction guidance system which operates to the height of about 12m
● Facts about the Very Narrow Aisle (VNA) Pallet
● Racking System
● Good stock rotation
● Good order picking, 100% selectivity
● Fast picking rate
● Good product protection
● Average floor area utilization
● 50% net pallet area ㎡ usage of overall warehouse area (based on the above diagrammatic illustration)
Description:
In a Very Narrow Aisle (VNA) pallet racking system, pallet racks can be placed closer together than other solutions because they are loaded and unloaded using a side loading fork truck. This enables aisles to be extremely narrow and ensures that space is used efficiently. With VNA pallet racking, the rotation of and access to stock is uncompromised and the amount of product stored in the warehouse is maximized. Typically, for \"very narrow aisles\" that are 1.8 metres wide, 45% more floor space can be made available than with a wide aisle solution.
Furthermore, not only does VNA pallet racking increase pallet storage by leveraging vertical space, but it maintains the advantages of selective racking by ensuring 100% selectivity.
Benefits & Features
Maximizes storage potential by reducing aisle space to a minimum
Reduces wasted space by using the vertical height of a building
All pallets are accessible to the lift trucks
Less product damage and fewer picking errors occur than with bulk stacking
Specifications:
|
● Maximum Height(Upright/Pillar): |
2,000mm - 12,000 mm |
|
● Max Width/Length(Beam): |
Up to 3,900 ,,m |
|
● Max Depth(Upright frame): |
Up to 1,500 mm |
|
● Max Weight: |
1000kg - 3000 kg / layer |
|
● Mobility: |
The height of each beam can be adjusted by 75mm of pitch freely. |
|
● Surface finish: |
Powder coating which is characterized by surface-smoothly, antirust,anti-corrosive, non-toxic. |
|
● Material: |
High quality steel, such as Q235B etc. |
|
● Color: |
Blue/Orange/Gray/others |
Competitive Advantage:
● Good quality and favorable price
● Multi function and widely used
● High picking rate to save work time
● Good product protection
● Making good use of space
● Dismountable structure, easily to assemble and disassemble
Remarks
A) Specification of the racking:Height*Width/Length*Depth
B) How many bays and layers
C) Load capacity of each layer
D) RAL color
E) Warehouse layout if possible(Auto CAD format)
