J53-300ton Pneumatic Forging Screw Press For Edge Cutting With Low Noise

FOB Price

Negotiable / Piece

1 Piece(Min.Order)

Supply Ability 0 Piece / Pieces per Month
Payment TermsT/T L/C D/P D/A
Delivery Detail7 days

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	Hongduan		Place of Origin	China
Model Number	J53-300ton

Product Description

Delivery Time:30-90 word day
Certification:ISO9001;CE

J53-300ton Pneumatic Forging Screw Press For Edge Cutting With Low Noise

Quick Detail:

1.simple and stable structure;

2.large energy;

3.low noise;

4.long lifetime;

5.safety and easy to operate and maintenance.

Nominal force from 160ton to 12500ton

Description:

J53 series double disc friction screw presses are widely used in the forging, extruding, edge cutting,

bending and adjusting of non-ferrous and ferrous metals.

this series machine has following advantages:

1.simple and stable structure;

2.large energy;

3.low noise;

4.long lifetime;

5.safety and easy to operate and maintenance.

Nominal force from 160ton to 12500ton

Applications:

J53 series double disc friction screw presses are widely used in the forging, extruding, edge cutting,

bending and adjusting of non-ferrous and ferrous metals.

Specifications:

J53 Series Double Disc Friction Screw Press

Main parameters	Unit	JA53-63	J53-100B	J53-160C	JA53-400D	J53-630D	J53-1000C
Nominal force	KN	630	1000	1600	4000	6300	10000
Energy	KJ	2.25	5	10	40	80	160
Max load (central loading)	kN	1000	1600	2500	6300	10000	16000
Ram stroke	mm	200	310	360	500	600	700
No. of stroke	min-1	35	19	17	14	11	10
Guide rail distance	mm	230	386	460	650	715	1000
Ram	front/back	mm	275	390	450	636	760	1190
dimension	left/right	mm	227	280	445	636	700	800
Dimention of	front/back	mm	315	500	560	820	920	1200
working table	left/right	mm	270	450	510	730	820	1000
Height of bolster	mm	80	100	-	120	180	200
Minimum die height	mm	235	220	260	400	470	500
Ejecting method		rigid	rigid	rigid	pneumatic	pneumatic	pneumatic
Ejecting stroke		50	80	50	100	100	100
	front/back	mm	1010	1393	2000	3200	4600	5355
Overall size	left/right	mm	1141	1884	2800	3600
