1600 KN J53-1600ton Friction Screw Press , Rigid Forging Screw Press For Ferrous Metals
- 0 Set / Sets per Month
- T/T L/C D/P D/A
- 7 days
You May Like
-
J53-2500ton Pneumatic Friction Screw Press With Low Noise For Extruding
-
J53-8000ton 630 KN Friction Screw Press With Large Energy For Edge Cutting
-
Rigid J53-100ton Hot Forging Press / Friction Screw Press For Bending
-
J53-160ton Stable Forging Screw Press / Hydraulic 1000 KN Hot Forging Press
-
J53-300ton Stable Pneumatic Metal Pressing Machine / Forging Screw Press For Edge Cutting
-
6300 kN Large Energy Hydraulic J53-400ton Forging Screw Press For Non-Ferrous Metals
Product Details
| Brand Name | Hongduan | Place of Origin | China | |
| Model Number | J53-1600ton |
Product Description
Certification:ISO9001;CE
1600 KN J53-1600ton Friction Screw Press , Rigid Forging Screw Press For Ferrous Metals
Quick Detail:
1.simple and stable structure;
2.large energy;
3.low noise;
4.long lifetime;
5.safety and easy to operate and maintenance.
Nominal force from 160ton to 12500ton
Description:
J53 series double disc friction screw presses are widely used in the forging, extruding, edge cutting,
bending and adjusting of non-ferrous and ferrous metals.
this series machine has following advantages:
1.simple and stable structure;
2.large energy;
3.low noise;
4.long lifetime;
5.safety and easy to operate and maintenance.
Nominal force from 160ton to 12500ton
Applications:
J53 series double disc friction screw presses are widely used in the forging, extruding, edge cutting,
bending and adjusting of non-ferrous and ferrous metals.
Specifications:
J53 Series Double Disc Friction Screw Press
| Main parameters | Unit | JA53-63 | J53-100B | J53-160C | JA53-400D | J53-630D | J53-1000C | |
| Nominal force | KN | 630 | 1000 | 1600 | 4000 | 6300 | 10000 | |
| Energy | KJ | 2.25 | 5 | 10 | 40 | 80 | 160 | |
|
Max load (central loading) |
kN | 1000 | 1600 | 2500 | 6300 | 10000 | 16000 | |
| Ram stroke | mm | 200 | 310 | 360 | 500 | 600 | 700 | |
| No. of stroke | min-1 | 35 | 19 | 17 | 14 | 11 | 10 | |
| Guide rail distance | mm | 230 | 386 | 460 | 650 | 715 | 1000 | |
| Ram | front/back | mm | 275 | 390 | 450 | 636 | 760 | 1190 |
| dimension | left/right | mm | 227 | 280 | 445 | 636 | 700 | 800 |
| Dimention of | front/back | mm | 315 | 500 | 560 | 820 | 920 | 1200 |
| working table | left/right | mm | 270 | 450 | 510 | 730 | 820 | 1000 |
| Height of bolster | mm | 80 | 100 | - | 120 | 180 | 200 | |
| Minimum die height | mm | 235 | 220 | 260 | 400 | 470 | 500 | |
| Ejecting method | rigid | rigid | rigid | pneumatic | pneumatic | pneumatic | ||
| Ejecting stroke | 50 | 80 | 50 | 100 | 100 | 100 | ||
| front/back | mm | 1010 | 1393 | 2000 | 3200 | 4600 | 5355 | |
| Overall size | left/right | mm | 1141 | 1884 | 2800 |
