Glavalume Steel Green Metal Roofing Tiles Color Coated Roofing Metal Shingle

Delivery Time:15 days after receiving the deposit
Certification:CE,SGS

glavalume steel Green Metal Roofing Tiles Color Coated Roofing metal Shingle

Quick Detail:

Technical details

Test item	result
Resistance to weathering	1000h: coating no cracks, no powder, no foam, no obvious discoloration
Heat resistance	90±2℃: no obvious change
Cold water resistance	-40±2℃: 24h no obvious change
Water resistance	240h: No foam, no no obvious change discoloration
UV resistance	60℃: 1000h no obvious change

The characteristics of colorful-stone coated metal roof tile

beautiful appearance: with the natual stone texture and strong stereoscopic sensation, and a variety of shapes, varied colors of tiles, have extremely good beautification effect the buliding longlife time :adopt hige strength ,high corrosion resistance aluminum zinc alloy steel plate, its corrosion resistance is 3-6 times than the corrosion resistance of galvanized steel , the surface material by weathering of natural stone particles or inorganic pigments dyeing natural gravel and water-based acrylic resin, products life up to more than 30 years. lighter weight: only equivalent material ,cement soil of 1/6, can reduce the load of the building,and it can reduce the cost of project, For the roof ,easy to transport and repeated construction and installation.. construction simole: to bending, cuting ,easy installation,simple ,low temperature season may construction energy conservation and environment protection:the heat reflective rate is 1.4-7 times than average roofing material ,easy energy saving ,using environment protection material ,and no harm to people and environment.

Name	Flat Metal Type
Overall Lenth	1340mm
Lenth of cover	1280mm
Width of cover	375mm
Roof cover	0.48sqm
Tiles/sqm	2.1pcs

TECHINICA INFO. ---->>>Material Composition---->>>Panel Layers

1)Steel The panels are structural grade steel, with a minimum tensile strength of 37ksi. They are rigid enough to tolerate reasonable loads, while allowing profile designs without the risks of cracking or significant elastic recovery.

2)Aluminum-Zinc Alloy Coating Protection for the rigid steel material is achieved when the steel passes through a bath of molten aluminum-zinc alloy. This coating combines the protection and strength of both aluminum and zinc. A significant benefit of the zinc component is its ability to protect exposed areas such as cut edges, drilled holes and scratches. Developers of the aluminum-zinc alloy coated steel have captured exposure data indicating corrosion protection of the underlying steel for more than 50 years in most environments.

3)Acrylic Priming System An acrylic coating is applied to both sides of the panel immediately after the application of the aluminum-zinc coatings. We developed this priming system in association
