PLC Resistance Winding Machine|resistance Wire Coil Winding M/c
- T/T L/C D/P D/A
- 7 days
You May Like
-
Resistance Wire Coil Winding Machine|DRS-23CNC Resistance Winding Machine
-
Resistance Winding Machine for Hot Runner Heaters|wire Coil Winding M/c
-
FM-12 Standard Filling Machine for Heaters
-
FM24-PLC Filling Machine for Heater|mgo Powder Filling Machine
-
X-Type Aluminum Filling Machine for Heaters
-
PLC MGO Powder Filling Machine FM48
Product Details
Brand Name | Feihong | Place of Origin | China | |
Model Number | RS-328 |
Product Description
The working theory of RS-328B resistance-wire winding machine for the manufacturing of compact spiral coils is to reel the coil to the payoff with a brake gear, guide the resistance wire to precision spinning by the wire carrier, and twine the wire around the core axle by an adjustable speed rotary device. The inside diameter of the coil is decided by the external diameter of the core axle, which can be altered free and controlled by coder and PLC touch screen. The resistance value needed could be set and amended on the touch screen to achieve resistance control. As long as the wire comes to the preset resistance, it would be cut through the displacement or the electromagnet. The PLC can record and control the quantities of the spiral coils, and the adjust control the rotational speed of the core axle.
