Q345B Steel Building Tower Crane For Construction , 65m Jib Length

Q345B Steel Building Tower Crane For Construction , 65m Jib Length

1. Specification: TC6015-8

2. Dimensions: standard section 2,000mmX2,000mmX3,000mm

3. Material: All main chord be made of  Q345B steel

4. Parameter: Maximum hoisting capacity is 8 m ons, the longest jib is 60m, maximum independent lifting height 59 m, maximum attached height is 180m.

5. Model number: QTZ125

 Quick Detail:

TC6015-8 tower crane (QTZ125)

1  Mast standard section :1,800mmX1,800mmX2,800mm ,1835mmX1835mmX2500mm,

   Plate standard section: 2,000mmX2,000mmX3,000mm.

2, The longest jib is 60m, the jib combination decreases progressively 5m each and the minimum jib length is 40m.

3, The maximum hoisting capacity is 8 tons.

 4, The maximum lifting capacity at a distance of 60m is 1.5 ton.

 5, The maximum hoisting moment is 135t.m.

 6, The maximum independent height is 59m and the maximum attached height is 180m.

 7,Hoisting mechanism: Adopting a double-speed winding motor   30KW .

   Slew mechanism: Adopting a double gyration winding motor  3.7 KWX2

   Hoisting mechanism: Adopting a double-speed winding motor   3.3KW

8,Tower crane foundation type: Embeded leg fixing type

                                                  Stone bolt fixing type

Our main products are:

Hammer head tower crane QTZ63(TC5013),QTZ80(TC5610,TC5610A,TC6010TC,TC6010A)QTZ100(TC6013-6,TC6013A-6,TC6013-8,TC6013A-8)QTZ125(TC6015-8,TC6015A-8,TC6512-10,TC6512A-10)QTZ160(TC7013-10,TC7013-12)QTZ250(TC7520-12,TC7520-16)

Table for main technical performance parameters for TC6015-8 tower crane:
