Home > Products > Electric Safety Tester > Temperature Meter for lamp caps. It's used to test the working and environmental temperature as well as temperature rise
Temperature Meter for lamp caps. It's used to test the working and environmental temperature as well as temperature rise
- 1000 Piece / Pieces per Month
- T/T L/C D/P D/A
- 7 days
You May Like
Product Details
| Brand Name | Chuangxin | Place of Origin | China | |
| Model Number | CX-T1 |
Product Description
Lamp Cap Temperature Rise Test System
CX-T1 is according to IEC60360-1998 and GB2512-2001(Standard method of measurement of lampcap temperature rise). It is used to test the working and environmental temperature as well as temperature-rise of the burner and lamp. It meets the requirement of IEC and GB Standards
• Channel sequence is displayed by 2 LED and temperature is displayed by 4 LED; Simultaneously display temperature rise curve
• Sensor: K type thermocouple and 8 channels for input temperature signal
• Temperature range: -40~300°C and testing accuracy: Class 0.5
• Capable of circle monitoring, single monitoring, printing and RS-232-C communication with PC
• Freely set up for channel sequence when circle monitoring
• Application software in Windows can track the changing of the selected channel temperature and provide print and save operation
• Dimension of standard testing box: 90x90x90cm (inner box) and 105x105x120cm (outer box), or customized; Lamp holder: E14, E27, E40, B22d and other holders
