HDD Mobile DVR GPS With Linux System , 8 Alarm Input

Name: HDD Mobile DVR GPS With Linux System , 8 Alarm Input
Brand: QOHO
SKU: 148823856
Availability: InStock

QOHO Technology Co.,Ltd

HDD Mobile DVR GPS With Linux System , 8 Alarm Input thumbnail-1

HDD Mobile DVR GPS With Linux System , 8 Alarm Input photo-1

Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)

Key Specifications

Get Latest Price

Brand Name:

QOHO

Place of Origin:

China

Model Number:

QH-MDVR8108HG

Contact Supplier Request Quote Chat Now

Payment & Shipping

Payment Methods:

Port of Shipment:

China

Delivery Detail:

7 days

Product Details
Company Profile
Contact Us

Brand Name QOHO

Place of Origin China

Model Number QH-MDVR8108HG

Delivery Time:Within 5-7 days after received payment
Certification:CE,FCC

HDD Mobile DVR GPS With Linux System , 8 Alarm Input

Description:

8 CH video & audio inputs; 4-CH D1&4-CH CIF H.264 video compression; Support 2.5\" 1TB hard disk or SSD and SD card max 128GB; Embedded a SD slot, support max 128GB SD; Eight alarm inputs,1 alarm output; Three RS485,one RS232; One RJ45 port; Two USB 2.0 port, back USB port is used to support the mirror record or back up record. Front USB port is used to export record file or upgrade firmware or import configure file. Embedded G-Sensor; Built-in GPS.

Product Technical parameters:

System	language	Chinese/ English
Operation system	Linux
Operation interface	Graphical User interface(OSD menu)
Password	User /Admin password
Control mode	IR remote control
Video	Video input	8-ch video composite input
Video output	1-ch composite output
Display mode	Single/ 8-ch video
Video compression	H.264 Main profile
PAL:100f at D1/s, NTSC: 120f at D1/s
Video Signal	NTSC,PAL
Audio	Audio input	8-ch audio input
Audio output	1-ch audio output
Recording mode	Audio & Video sync Recording
Phone	Support IP call and analog voice call
Image processing & storage	Image format mode	CIF/HD1/D1 optional
Video stream Standard	ISO14496-10
Video bitrate	CIF: 1536Kbps ~ 128Kbps,4 levels optional.
Highest:0 level; Lowest: 3 level
HD1: 2048Kbps ~ 512Kbps,4 levels optional.
Highest:0 level; Lowest: 3 level
D1: 4Mbps ~ 1Mbps,4 levels optional.
Highest:0 level; Lowest: 3 level
Audio Bitrate	8KB/s
Storage	Built-in a SATA HDD, support HDD Max 2.5\" 1TB;
And built-in a SD card, Support SD card Max 128GB;
Alarm	Alarm input	8 alarm input, below 4V is low level alarm, above 4V are high level alarm
Alarm output	2 alarm output, output high level:12V
Communication Interface	RS485 Interface	Support 3-RS485 interface
RS232 Interface	Support 1-RS232 interface
WIFI Interface	Support RJ45 interface external 802.11b/g
USB interface	Include 2 USB interfaces,1 USB interface connect with external Vehicle Black data box, another USB interface to upgrade software and copy data.
