High Resolution P6 Indoor LED Video Display for Advertising With WIN 98 / 2000 / XP

Item

Technical parameters

1,Module

1)physical pitch: 6mm

2)physical density:27777 dot/m2

3)pitch composing: 1R1G1B

4)LED specification:SMD3528

R:625-630nm; 150-200mcd

  G:520-525nm; 260-330mcd

B:465-470nm; 55-65mcd

5)module size: (length)192mm×(width)96mm

6)parse of single module: 32*16 dot

2,Screen

1)best distance: ≥5m

2)best angle: horizontal axis110°,vertical axis45°

3)operating temperature : for store -40°C ~ +85°C,for working -20°C ~ +50°C

4)Relative humidity: 10%~95%

3,Voltage

1)working voltage: AC220V±10%, 50Hz

2)Avg. power consumption: 450~500W/m2

3)Max power consumption: ≤1000W/m2

4,Control system

1)Host control: P4, CPU2.0G,1G memory,80G hard drive,or the same grade more than the computer

2)operating system: WIN 98/ 2000/XP etc.

3)control way: synchronous or asynchronous

4)display card: DVI card

5)editing card: PCIV card

5,Main technical parameters

1)drive device: LED driver using the device-specific

2)drive way : 1/8 constant current driving

3)video frame rate: ≥60Hz/s

4)refresh rate: ≥240 Hz/s

5)grey scale/colors: can display 16.7M colors

6) white balanced brightness: ≥2000cd/m2

7)brightness adjusted by: software adjustable regulator 16

8)control system: PCIV card(optional)+ DVI display card+ host to control the card +fiber optic transmission(optional)

9)MTBF: ≥10000 hours

10)lifespan: 100000 hours

11)evenly between: Pixel light intensity, brightness uniformity module

12)switching power supply load: 5V/40A

13) display mode: 1024×768

6,Software

LED studio

7,Protect technology

Moisture, dust, corrosion, anti-static, anti-lightning, and with the flow, short circuit, over voltage, under voltage protection function

8,Playback

Text files, WORD files, all image files (BMP / JPG / GIF / PCX ...), all the animation files (MPG / MPEG / MPV / MPA / AVI / VCD / SWF / RM / RA / RMJ /).

9,Assembly structure

Modular unit design, graphic modular - Display cabinet - display assembly of composite structures to facilitate assembly
